Converter Electrical Characteristics

(Continued)

The following specifications apply for V

A

= DR V

D

= +3.0V

DC

, V

RT

= +1.9V, V

RB

= 0.3V, C

L

= 10 pF, f

CLK

= 60 MHz at 50%

duty cycle. Boldface limits apply for T

J

= T

MIN

to T

MAX

: all other limits T

A

= 25˚C (Notes 7, 8)

Symbol

Parameter

Conditions

Typical

(Note 9)

Limits

(Note 9)

Units

(Limits)

POWER SUPPLY CHARACTERISTICS

PC

Power Consumption

DC Input

76

96

mW (max)

f

IN

= 10 MHz, V

IN

= FS − 3 dB,

PD = Low

88

mW

CLK Low, PD = Hi

0.6

mW

PSRR

1

Power Supply Rejection Ratio

FSE change with 2.7V to 3.3V change

in V

A

54

dB

PSRR

2

Power Supply Rejection Ratio

SNR change with 200 mV at 200 kHz

on supply

45

dB

AC ELECTRICAL CHARACTERISTICS

f

C1

Maximum Conversion Rate

70

60

MHz (min)

f

C2

Minimum Conversion Rate

20

MHz

t

CL

Minimum Clock Low Time

6.7

ns (min)

t

CH

Minimum Clock High Time

6.7

ns (min)

t

OH

Output Hold Time

CLK Rise to Data Invalid

4.4

ns

t

OD

Output Delay

CLK Rise to Data Valid

8.2

12

ns (max)

Pipeline Delay (Latency)

2.5

Clock Cycles

t

AD

Sampling (Aperture) Delay

CLK Fall to Acquisition of Data

1.5

ns

t

AJ

Aperture Jitter

2

ps rms

Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is
functional, but do not guarantee specific performance limits. For guaranteed specifications and test conditions, see the Electrical Characteristics. The guaranteed
specifications apply only for the test conditions listed. Some performance characteristics may degrade when the device is not operated under the listed test
conditions.

Note 2: All voltages are measured with respect to GND = AGND = DR GND = 0V, unless otherwise specified.

Note 3: When the input voltage at any pin exceeds the power supplies (that is, less than AGND or DR GND, or greater than V

A

or DR V

D

), the current at that pin

should be limited to 25 mA. The 50 mA maximum package input current rating limits the number of pins that can safely exceed the power supplies with an input
current of 25 mA to two.

Note 4: The absolute maximum junction temperature (T

J

max) for this device is 150˚C. The maximum allowable power dissipation is dictated by T

J

max, the

junction-to-ambient thermal resistance (

θ

JA

), and the ambient temperature (T

A

), and can be calculated using the formula P

D

MAX = (T

J

max − T

A

) /

θ

JA

. In the 24-pin

TSSOP,

θ

JA

is 92˚C/W, so P

D

MAX = 1,358 mW at 25˚C and 435 mW at the maximum operating ambient temperature of 85˚C. Note that the power consumption of

this device under normal operation will typically be about 180 mW (88 mW quiescent power +12 mW reference ladder power). The values for maximum power
dissipation listed above will be reached only when the ADC08060 is operated in a severe fault condition (e.g., when input or output pins are driven beyond the power
supply voltages, or the power supply polarity is reversed). Obviously, such conditions should always be avoided.

Note 5: Human body model is 100 pF capacitor discharged through a 1.5 k

Ω resistor. Machine model is 220 pF discharged through ZERO Ohms.

Note 6: See AN-450, “Surface Mounting Methods and Their Effect on Product Reliability”, or the section entitled “Surface Mount” found in any post 1986 National
Semiconductor Linear Data Book, for other methods of soldering surface mount devices.

Note 7: The analog inputs are protected as shown below. Input voltage magnitudes up to V

A

+ 300 mV or to 300 mV below GND will not damage this device.

However, errors in the A/D conversion can occur if the input goes above DR V

D

or below GND by more than 100 mV. For example, if V

A

is 2.7V

DC

the full-scale input

voltage must be

≤2.6V

DC

to ensure accurate conversions.

20006207

Note 8: To guarantee accuracy, it is required that V

A

and DR V

D

be well bypassed. Each supply pin must be decoupled with separate bypass capacitors.

Note 9: Typical figures are at T

J

= 25˚C, and represent most likely parametric norms. Test limits are guaranteed to National’s AOQL (Average Outgoing Quality

Level).
