ISD1700 SERIES

Publication Release Date: January 23, 2007

- 7 -

Revision 1.3-S2

5 PIN

DESCRIPTION

Refer to Design Guide for details before performing any design or PCB layout.

PIN NAME

FUNCTIONS

V

CCD

Digital Power Supply

: Power supply for digital circuitry.

LED

LED

: An LED output.

RESET

RESET

: When active, the device enters into a known state.

MISO

Master In Slave Out:

Data is shifted out on the falling edge of SCLK.

When the SPI is inactive (

SS

= high), it’s tri-state.

MOSI

Master Out Slave In:

Data input of the SPI interface when ISD1700 is a

slave. Data is latched into the device on the rising edge of SCLK.

SCLK

Serial Clock:

Clock of the SPI interface.

SS

Slave Select:

Selects as a slave device and enables the SPI interface.

V

SSA

Analog Ground

: Ground path for analog circuitry.

AnaIn

AnaIn:

Auxiliary analog input to the device for recording or feed-through.

MIC+

MIC+:

Non-inverting input of the differential microphone signal.

MIC-

MIC-:

Inverting input of the differential microphone signal.

V

SSP2

Ground

: Ground path for negative PWM speaker drive.

SP-

SP-

: The negative Class D PWM speaker output.

V

CCP

Power Supply for PWM Speaker Driver

: Power for PWM speaker drive.

SP+

SP+:

The positive Class D PWM speaker output.

V

SSP1

Ground

: Ground path for positive PWM speaker drive.

AUD/AUX Auxiliary Output: Either an AUD (current) or AUX (voltage) output.

AGC

Automatic Gain Control (AGC)

: The AGC adjusts the gain of the

microphone preamplifier circuitry.

VOL

Volume:

This control has 8 levels of volume adjustment.

R

OSC

Oscillator Resistor

: A resistor determines the sample frequency of the

device, which sets the duration.

V

CCA

Analog Power Supply

. Power supply for analog circuitry.

FT

Feed-through:

Enable the feed-through path for AnaIn signal to the

outputs.

PLAY

Playback:

Plays the recorded message individually, or plays messages

sequential in a looping mode.

REC

Record:

When active, starts recording message.

ERASE

Erase:

When active, can erase individual message or do global erase.

FWD

Forward:

Advances to the next message from the current location.

INT

RDY

An open drain output. Can review ready or interrupt status.

V

SSD

Digital Ground

: Ground path for digital circuitry
