ISD1700 SERIES
Publication Release Date: January 23, 2007
- 13 - Revision 1.3-S2
8 ABSOLUTE MAXIMUM RATINGS
ABSOLUTE MAXIMUM RATINGS (DIE)
[1]
CONDITIONS VALUES
Junction temperature 150 0 C
Storage temperature range -65 0 C to +150 0 C
Voltage Applied to any pads (V
SS
- 0.3V) to (V
CC
+ 0.3V)
Power supply voltage to ground potential -0.3V to +7.0V
ABSOLUTE MAXIMUM RATINGS (PACKAGED PARTS)
[1]
CONDITIONS VALUES
Junction temperature 150 0 C
Storage temperature range -65 0 C to +150 0 C
Voltage Applied to any pins (V
SS
- 0.3V) to (V
CC
+ 0.3V)
Voltage applied to any pin (Input current limited to +/-20 mA) (V
SS
– 1.0V) to (V
CC
+ 1.0V)
Power supply voltage to ground potential -0.3V to +7.0V
[1]
Stresses above those listed may cause permanent damage to the device. Exposure to the absolute
maximum ratings may affect device reliability. Functional operation is not implied at these conditions.
8.1 O PERATING C ONDITIONS
OPERATING CONDITIONS (DIE)
CONDITIONS VALUES
Operating temperature range 0°C to +50°C
Supply voltage (V
CC
) [1] +2.4 V to +5.5 V
Ground voltage (V
SS
) [2] 0 V
Input voltage (V
CC
) [1] 0 V to 5.5 V
Voltage applied to any pins (V
SS
–0.3 V) to (V
CC
+0.3 V)
OPERATING CONDITIONS (PACKAGED PARTS)
CONDITIONS VALUES
Operating temperature range (Case temperature) -40°C to +85°C
Supply voltage (V
DD
) [1] +2.4V to +5.5V
Ground voltage (V
SS
) [2] 0V
Input voltage (V
DD
) [1] 0V to 5.5V
Voltage applied to any pins (V
SS
–0.3V) to (V
DD
+0.3V)
[1] V
CC
= V
CCA
= V
CCD
= V
CCP
[2] V
SS
= V
SSA
= V
SSD
= V
SSP1
V
SSP2
