DS1386/1386P
11 of 20
ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground -0.3V to +7.0V
Operating Temperature 0°C to 70°C
Storage Temperature -40°C to +70°C
Soldering Temperature See J-STD-020A Specification (See Note 14)
* This is a stress rating only and functional operation of the device at these or any other conditions above
those indicated in the operation sections of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods of time may affect reliability.
RECOMMENDED DC OPERATING CONDITIONS (0 °C to 70°C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Supply Voltage V
CC
4.5 5.0 5.5 V 10
Input Logic 1 V
IH
2.2 V
CC
+0.3 V 10
Input Logic 0 V
IL
-0.3 +0.8 V 10
DC ELECTRICAL CHARACTERISTICS (0 °C to 70°C; V
CC
= 5.0V ± 10%)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Leakage Current I
IL
-1.0 +1.0 µA
Output Leakage Current I
LO
-1.0 +1.0 µA
I/O Leakage Current I
LIO
-1.0 +1.0 µA
Output Current @ 2.4V I
OH
-1.0 mA
Output Current @ 0.4V I
OL
2.1 mA 13
Standby Current CE =2.2V I
CCS1
3.0 7.0 mA
Standby Current CE =V
CC
-0.5 I
CCS2
2.0 4.0 mA
Active Current I
CC
85 mA
Write Protection Voltage V
TP
4.0 4.25 4.5 V
CAPACITANCE (t
A
=25 °C)
PARAMETER SYMBOL MIN TYP MAX UNITS NOTES
Input Capacitance C
IN
7 15 pF
Output Capacitance C
OUT
7 15 pF
Input/Output Capacitance C
I/O
7 15 pF
