Standard ICs BU4015B / BU4015BF
•
Absolute maximum ratings (V
SS
= 0V, Ta = 25°C)
Parameter Symbol Limits Unit
Power supply voltage V
DD
– 0.3 ~ + 18 V
Power dissipation Pd 1000 (DIP), 500 (SOP) mW
Operating temperature Topr – 40 ~ + 85
°
C
Storage temperature Tstg – 55 ~ + 150
°
C
Input voltage V
IN
– 0.3 ~ V
DD
+ 0.3 V
•
Electrical characteristics
DC characteristics (unless otherwise noted, Ta = 25°C, V
SS
= 0V)
Parameter Symbol Min. Typ. Max. Unit Conditions
V
DD
(V)
Input high level voltage V
IH
3.5 — —
V
5
— 7.0 — — 10
11.0 — — 15
Input low level voltage V IL
— — 1.5
V
5
— — — 3.0 10
— — 4.0 15
Input high level current I IH — — 0.3
µ
A 15 V IH = 15V
Input low level current I IL — — – 0.3
µ
A 15 V IL = 0V
Output high level voltage V OH
4.95 — —
V
5
I O = 0mA 9.95 — — 10
14.95 — — 15
Output low level voltage V OL
— — 0.05
V
5
I O = 0mA — — 0.05 10
— — 0.05 15
Output high level current I
OH
– 0.16 — —
mA
5 V
OH
= 4.6V
– 0.4 — — 10 V
OH
= 9.5V
– 1.2 — — 15 V
OH
= 13.5V
Output low level current I
OL
0.44 — —
mA
5 V
OL
= 0.4V
1.1 — — 10 V
OL
= 0.5V
3.0 — — 15 V
OL
= 1.5V
Static current dissipation I
DD
— — 20
µ
A
5
V
I
= V
DD
or GND — — 40 10
— — 80 15
