DS7505
Digital Thermometer and Thermostat
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
DC ELECTRICAL CHARACTERISTICS
(1.7V ≤ V
DD
≤ 3.7V, T
A = -55°C to +125°C, unless otherwise noted.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage Range on VDD Relative to Ground ..........-0.3V to +4.0V
Voltage Range on Any Other Pin
Relative to Ground.............................................-0.3V to +6.0V
Operating Temperature Range .........................-55 °C to +125°C
Storage Temperature Range .............................-55 °C to +125°C
Soldering Temperature...........................Refer to the IPC/JEDEC
J-STD-020 Specification.
PARAMETER SYMBOL CONDITIONS MIN MAX UNITS
Supply Voltage V DD 1.7 3.7 V
Input Voltage Range (SDA, SCL,
O.S., A0, A1, A2)
(Note 1) -0.3 +5.5 V
0°C to +70°C ± 0.5
Thermometer Error
(Note 2, 3)
T ERR
-55°C to +125°C ± 2.0
°C
Input Logic-High V IH (Note 1) 0.7 × V DD V
Input Logic-Low V IL (Note 1) 0.3 × V DD V
SDA Output Logic-Low Voltage V OL1 6mA sink current (Note 1) 0 0.6 V
O.S. Saturation Voltage V OL2 4mA sink current (Notes 1, 2) 0.8 V
Input Current Each I/O pin 0.4V < V I/O < 0.9 x V DD -10 +10 μA
I/O Capacitance C I/O 10 pF
Standby Current I DD1 (Notes 4, 5, 6) 2 μA
Active temp conversions 750
Communication only 100
Active Current
(Notes 4, 5, 6)
I DD
E 2 Copy only 500
μA
AC ELECTRICAL CHARACTERISTICS
(1.7V ≤ V
DD
≤ 3.7V, T
A = -55°C to +125°C, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Resolution 9 12 Bits
9-bit conversions 25
10-bit conversions 50
11-bit conversions 100
Temperature Conversion Time t CONVT
12-bit conversions 200
ms
SCL Frequency f SCL 400 kHz
EEPROM Copy Time t WR -40°C to +85°C 10 ms
-40°C T A +85°C (Note 7) 10k 20k
EEPROM Copy Endurance N EEWR
T A = +25°C (Note 7) 40k 80k
Cycles
