Standard ICs BA4560 / BA4560F / BA4560N
•
Internal circuit configuration
V CC
V EE
R 2 R 3
R 1
Q 5
Q 1
– IN
+ IN
Q 2
Q 6
Q 9
Q 8
Q 4 Q 3
R 4
Q 10
Q 7
Q 11
R 9 D
Q 13
R 5
R 6
R 7
Q 12 Q 14
Q 15
R 8
OUT
•
Absolute maximum ratings (Ta = 25°C)
Parameter Symbol
Limits
Unit
BA4560 BA4560F BA4560N
Power supply voltage V
CC
±
18
±
18
±
18 V
Power dissipation 800
∗
550
∗
900
∗
mW
Differential input voltage V
ID
±
V
CC
V
Common-mode input voltage V
I
V
Operating temperature Topr
°
C
Storage temperature Tstg
°
C
– 40 ~ + 85
– 55 ~ + 125
Pd
∗
Refer to the Pd characteristics diagram. The values for the BA4560F are those when it is mounted on a glass
epoxy PCB (50mm
×
50mm
×
1.6mm).
– V
CC
~ V
CC
•
Electrical characteristics (unless otherwise noted, Ta = 25°C, V
CC
= +15 V, V
EE
= -15 V)
Parameter Symbol Min. Typ. Max. Unit Conditions
Input offset voltage V
IO
— 0.5 6.0 mV R
S
Ϲ 10k
Ω
Input offset current I
IO
— 5 200 nA
Input bias current I
B
— 50 500 nA
High-amplitude voltage gain A
V
86 100 — dB R
L
м 2k
Ω
, V
O
=
±
10V
Common-mode input voltage V
ICM
±
12
±
14 — V
Maximum output voltage 1 V
OM1
±
12
±
14 — V R
L
м 10k
Ω
Maximum output voltage 2 V
OM2
±
10
±
13 — V R
L
м 2k
Ω
Common-mode rejection ratio CMRR 70 90 — dB R
S
Ϲ 10k
Ω
Power supply voltage rejection ratio PSRR — 30 150 R
S
Ϲ 10k
Ω
Slew rate S. R. — 4.0 — V /
µ
s A
V
= 1, R
L
= 2k
Ω
Input conversion noise voltage Vn — — 2.2
µ
V
Gain band width product GBW — 10 — MHz
µ
V / V
f = 10kHz
