ABSOLUTE MAXIMUM RATINGS
RECOMMENDED OPERATING CONDITIONS
(TA = -40°C to +125°C.)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Voltage on V
CC
Relative to Ground.......................-0.5V to +6.0V
Voltage on DR, SEL0, SEL1 Relative
to Ground* ..............................................-0.5V to (V
CC
+ 0.5V)
Operating Temperature Range .........................-40°C to +125°C
Storage Temperature Range .............................-55°C to +125°C
Soldering Temperature...................See J-STD-020 Specification
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
V
CC
(Note 1)
3.0
3.3
3.6
V
High-Level Input Voltage
(SEL0, SEL1, DR)
V
IH
0.7 x
V
CC
V
CC
+
0.3
V
Low-Level Input Voltage
(SEL0, SEL1, DR)
V
IL
-0.3
0.3 x
V
CC
V
DC ELECTRICAL CHARACTERISTICS
(T
A
= -40°C to +125°C; V
CC
= +3.0V to +3.6V, unless otherwise noted.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
High-Level Output Voltage (OUT)
V
OH
I
OH
= -4mA, V
CC
= 3.0V
2.4
V
Low-Level Output Voltage (OUT)
V
OL
I
OL
= 4mA
0.4
V
High-Level Input Current
(SEL0, SEL1, DR)
I
IH
V
CC
= 3.6V
1
µA
Low-Level Input Current
(SEL0, SEL1, DR)
I
IL
V
IL
= 0
-1
µA
Supply Current (Active)
I
CC
(Note 2)
16
mA
*
This voltage must not exceed 6.0V.
AC ELECTRICAL CHARACTERISTICS
(T
A
= -40°C to +125°C; V
CC
= +3.0V to +3.6V, unless otherwise noted.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Output Frequency Range
f
OUT
(Note 3)
0.130
66.6
MHz
V
CC
= 3.3V, T
A
= +25°C
-0.25
0
+0.25
Across T
A
and V
CC
-1.75
+1.75
Output Center Frequency Tolerance
Δf
OUT
0°C to +70°C, across V
CC
-1.2
+1.2
%
Power-Up Time
t
PU
(Note 4)
0.1
ms
Load Capacitance
C
L
15
50
pF
DS1091L
Automotive Temperature Range
Spread-Spectrum Econoscillator
