Standard ICs BU4094BC / BU4094BCF / BU4094BCFV
•
Absolute maximum ratings (Ta = 25°C)
Parameter Symbol Limits Unit
Power supply voltage V
DD
V
Power dissipation mW
Operating temperature Topr
°
C
Storage temperature Tstg
°
C
Input voltage V
IN
V – 0.5 ~ V
DD
+ 0.5
Pd
– 0.5 ~ + 20
– 55 ~ + 150
– 40 ~ + 85
1000 (DIP), 500 (SOP)
400 (SSOP)
•
Electrical characteristics
DC characteristics (unless otherwise noted, V
SS
= 0V, Ta = 25°C)
Parameter Symbol Min. Typ. Max. Unit Conditions
V
DD
(V)
Input high level voltage
Input low level voltage
Input high level current
Input low level current
Output high level voltage
Output low level voltage
Output high level current
Output low level current
Static current dissipation
Output high level
disable current
Output low level
disable current
V
IH
3.5 — —
V
5
— 7.0 — — 10
11.0 — — 15
V
IL
— — 1.5
V
5
— — — 3.0 10
— — 4.0 15
I
IH
— — 0.3
µ
A 15 V
IH
= 15V
I
IL
— — – 0.3
µ
A 15 V
IL
= 0V
V
OH
4.95 — —
V
5
I
O
= 0mA 9.95 — — 10
14.95 — — 15
V
OL
— — 0.05
V
5
I
O
= 0mA — — 0.05 10
— — 0.05 15
I
OH
– 0.44 — —
mA
5 V
OH
= 4.6V
– 1.1 — — 10 V
OH
= 9.5V
– 3.0 — — 15 V
OH
= 13.5V
I
OL
0.44 — —
mA
5 V
OL
= 0.4V
1.1 — — 10 V
OL
= 0.5V
3.0 — — 15 V
OL
= 1.5V
I
DD
I
DH
— — 20
µ
A
µ
A
5
V
I
= V
DD
, or GND
V
OUT
= 15V
— — 40 10
— — 80
— — 1.0
15
15
I
DL
µ
A V
OUT
= 0V — — – 1.0 15
