DS1803
5 of 11
allows the user to write both potentiometers to the same value with one command and one data value
being issued.
All the write operations begin with a START condition. Following the START condition, the master
device will issue the control byte. The read/write bit of the control byte will be set to ‘0’ for writing the
DS1803. Once the control byte has been issued and the master receives the acknowledgment from the
DS1803, the command byte is transmitted to the DS1803. As mentioned above, there exist three write
operations that can be used with the DS1803. The binary value of each write command is shown in Figure
5 and also in the Table 1.
2-WIRE COMMAND WORDS Table 1
COMMAND COMMAND VALUE
Write Potentiometer-0 101010 01
Write Potentiometer-1 101010 10
Write Both Pots 101011 11
