MAX6613
Low-Voltage Analog Temperature
Sensor in an SC70 Package
_______________________________________________________________________________________ 3
Typical Operating Characteristics
(R L = ∞Ω, T
A = +30 °C, unless otherwise noted.)
STEP RESPONSE FROM +25 °C TO +125°C
MAX6613 toc05
1.55V
430mV
1s/div
200mV/div
V OUT
SUPPLY CURRENT vs. TEMPERATURE
MAX6613 toc04
TEMPERATURE ( °C)
SUPPLY CURRENT (
µ
A)
110 95 65 80 -10 5 20 35 50 -25
5.5
6.0
6.5
7.0
7.5
8.0
8.5
9.0
9.5
10.0
5.0
-40 125
V CC = 2.7V
V CC = 5V
V
CC
= 3.3V
SUPPLY CURRENT vs. SUPPLY VOLTAGE
MAX6613 toc03
SUPPLY VOLTAGE (V)
SUPPLY CURRENT (
µ
A)
5.0 4.0 1.0 2.0 3.0
1
2
3
4
5
6
7
8
9
10
0
0 6.0
OUTPUT VOLTAGE vs. SUPPLY VOLTAGE
MAX6613 toc02
SUPPLY VOLTAGE (V)
OUTPUT VOLTAGE (V)
5.0 4.0 3.0 2.0 1.0
1.482
1.484
1.486
1.488
1.490
1.492
1.494
1.496
1.498
1.500
1.502
1.504
1.506
1.508
1.510
1.480
0 6.0
OUTPUT VOLTAGE vs. TEMPERATURE
MAX6613 toc01
TEMPERATURE ( °C)
OUTPUT VOLTAGE (V)
110 95 80 65 50 35 20 5 -10 -25
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2.0
2.1
2.2
2.3
0.4
-40 125
PIN NAME FUNCTION
1 N.C. No Connection. Must be connected to ground or left floating.
2 GND Ground. Should be connected to pin 5. May be left floating, if desired.
3 OUT Voltage Output
4 V CC Supply Voltage. Bypass to GND with a 0.1µF capacitor.
5 GND Ground
Pin Description
