MAX14525
Battery Switch with Four Enable Inputs
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL CHARACTERISTICS
(V
BAT
= +2.2V to +5.5V, T
A
= -40°C to +85°C, unless otherwise noted. Typical values are at V
BAT
= +3.6V and T
A
= +25°C.)
(Note 2)
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
Note 1: Package thermal resistances were obtained using the method described in JEDEC specification JESD51-7, using a four-layer
board. For detailed information on package thermal considerations, refer to www.maxim-ic.com/thermal-tutorial .
(All voltages referenced to GND.)
IN, BAT, JIG, S_EN, ON_K ................................... -0.3V to +6.0V
TA ...........................................................................-0.3V to +28V
Continuous Power Dissipation (T
A
= +70°C)
8-Pin TDFN (derate 11.9 mW/°C above +70°C) .........954 mW
Junction-to-Case Thermal Resistance
( θ
JC
) (Note 1) ...............................................................37°C/W
Junction-to-Ambient Thermal Resistance
( θ
JA
) (Note 1) ...............................................................84°C/W
Operating Temperature Range .......................... -40°C to +85°C
Junction Temperature ..................................................... +150°C
Storage Temperature Range ............................ -65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
DC CHARACTERISTICS
Input Voltage Range V BAT , V IN 2.2 5.5 V
On-Resistance R ON I LOAD = 100mA, V BAT = +3.0V 35 90 m Ω
Disable Supply Current I
BAT_DIS
V BAT = +5.5V
(V JIG = V S_EN = V ON_K = V TA = V IN = 0)
1 µA
V BAT Supply Current I BAT V JIG = V S_EN = V BAT , V ON_K = V TA = 0 0.8 4.5 µA
Increase in Supply Current with
V
JIG /V S_EN Voltage
ΔI
BAT
V
JIG
= V
S_EN
= V
IH
or V
IL
2 µA
Increase in Supply Current with
V
ON_K
Voltage
ΔI
BAT V BAT = V ON_K = +3.6V 4.5 µA
Peak Current I LIM V BAT = +3.6V 5 A
UVLO Undervoltage Lockout Ramping V BAT 1.9 V
LOGIC INPUT
TA Threshold Voltage V TA_TH 1.15 1.7 2.5 V
TA Threshold Hysteresis 1%
TA Input Resistance V TA = 1V 50 100 180 k Ω
JIG, S_EN Input Logic-High V IH 1.4 V
JIG, S_EN Input Logic-Low V IL 0.4 V
JIG, S_EN Input Leakage Current I
IN
V
BAT
= +5.5V -200 +200 nA
IN AND Gate Threshold Voltage V IN_TH
0.3 x
V
BAT
0.6 x
V
BAT
V
ON_K Threshold Voltage V ON_K_TH
Low-to-high transition
(Figure 1)
2.94 3.0 3.06 V
ON_K Threshold Hysteresis 1%
