MAX4330–MAX4334
Single/Dual/Quad, Low-Power, Single-Supply,
Rail-to-Rail I/O Op Amps with Shutdown
______________________________________________________________________________________ 15
P
D E
F
W
P2 P0
D1
A0
B0
K0
t
±0.102
±0.102
A
0
B
0
D
D
1
3.200
3.099
1.499
0.991
±0.102
±0.051
±0.102
±0.102
1.753
3.505
1.397
3.988
E
F
K
0
P
+0.102
+0.000
NOTE: DIMENSIONS ARE IN MM.
AND FOLLOW EIA481-1 STANDARD.
+0.305
-0.102
+0.254
+0.000
P
0
3.988 ±0.102
P
0
10 40.005 ±0.203
P
2
2.007 ±0.051
t 0.254 ±0.127
W 8.001
5 SOT23-5
Tape-and-Reel Information
Chip Information
MAX4330/MAX4331
TRANSISTOR COUNT: 199
SUBSTRATE CONNECTED TO V
EE
MAX4332/MAX4333
TRANSISTOR COUNT: 398
SUBSTRATE CONNECTED TO V
EE
MAX4334
TRANSISTOR COUNT: 796
SUBSTRATE CONNECTED TO V
EE
