Typical Performance Characteristics
t
CRD
vs Temperature
Reference Voltage
Linearity Error vs
Reference Voltage
Offset Error vs
vs Temperature
Supply Current
vs Temperature
Logic Threshold
vs Temperature
Output Current
TL H 11086 – 24
Connection Diagrams
TL H 11086 – 14
Dual-In-Line and Wide-Body
Small-Outline
Packages J20A N20A or M20B
TL H 11086 – 15
Dual-In-Line and Wide-Body
Small-Outline
Packages N20A or M20B
Ordering Information
Industrial (b40 C
s
T
A
s
85 C)
Package
ADC08061BIN ADC08061CIN
N20A
ADC08062BIN ADC08062CIN
ADC08061BIWM ADC08061CIWM
M20B
ADC08062BIWM ADC08062CIWM
ADC08061CMJ 883 5962
J20A
http
www national com
9
