RPR-220
Sensors
3/3
1
10
100
0 2 4 6 8 10 12 14
DISTANCE : d ( mm)
RELATIVE COLLECTOR WRRENT : I
C
(%)
Fig.7 Relative output vs. distance
RELATIVE COLLECTOR CURRENT : I
C
(%)
AMBIENT TEMPERATURE : Ta ( ° C)
− 40 − 60 − 20 0 20 40 60 80 100
0
20
40
60
80
100
120
160
140
Fig.8 Relative output vs. ambient
temperature
Fig.9 Forward current vs.
ambient temperature
FORWARD CURRENT : I
F
(
mA)
0 20 40 60 80 100
20
80
100
60
40
0
AMBIENT TEMPERATURE : Ta ( ° C)
! ! ! ! Circuit for testing transfer characteristics
V CC
I C I F
d=6mm
Reflection plate
V CC =2V
I F =10mA
