Rainbow Electronics SIM-20ST User Manual
Infrared light emitting diode, side-view type, Sim-20st, Sensors

F
External dimensions (Units: mm)
192
Sensors
Infrared light emitting diode, side-view
type
SIM-20ST
The SIM-20ST is a GaAs infrared light emitting diode with a side-facing detector. High output with
φ
1.85 lens.
F
Applications
Light source for sensors
F
Features
1) Compact package (4.4
4.3 mm) with lens.
2) High efficiency, high output P
O
= 7 mW
(I
F
= 50 mA).
3) Emission spectrum well suited to silicon detectors
(
λ
P
= 950 nm).
4) Good current-optical output linearity.
5) Long life, high reliability.
F
Absolute maximum ratings (Ta = 25
_
C)
