MAX15034
R T
24.9k Ω
R8
60.4k Ω
R5
4.75k
Ω
R4
5.11k
Ω
C6
680 μF
1.3V/20A
R1
2m Ω
L1
0.8 μH
Q1
IRF7832
Q2
IRF7821 C8
0.1 μF
D1
(100mA, 30V)
C2
1 μF
Q4
IRF7821
D2
(100mA, 30V)
C3
0.1
μF
C4
4.7
μF
R3
1 Ω
C5
10
μF
V IN
C9
0.1
μF
Q3
IRF7832
L2
0.8 μH R2
2m Ω
R14
1k Ω
C10
15nF
C11
120pF
R15
1k Ω
C12
15nF
C13
120pF
AGND AVGLIMIT RT/CLKIN
EN2
EN1
EAOUT1
EAN1
CSP1
CSN1
DL1
LX1
DH1
BST1
V DD
IN REG
BST2
DH2
LX2
DL2
PGND
CSP2
CSN2
EAN2
EAOUT2
MODE
CLP1
CLP2
MAX15034
EXTERNAL FREQUENCY SYNC
22 Ω
22 Ω
TO REG
V REG R16
100k Ω
R17
100k Ω
C14
0.1
μF
C15
0.1 μF
PGND
Figure 7. Dual-Phase, Single-Output Buck Regulator
Configurable, Single-/Dual-Output, Synchronous
Buck Controller for High-Current Applications
