MAX5547
Dual, 10-Bit, Current-Sink Output DAC
2 _______________________________________________________________________________________
ABSOLUTE MAXIMUM RATINGS
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.
V DD to GND .............................................................-0.3V to +6V
OUTA, OUTB, REF to GND ........................-0.3V to (V DD + 0.3V)
SCLK, DIN, CS to GND ............................................-0.3V to +6V
Continuous Power Dissipation (T A = +70°C)
8-Pin TDFN (derate 18.2mW/°C above +70°C) .......1454.5mW
Operating Temperature Range ...........................-40°C to +85°C
Junction Temperature .....................................................+150°C
Storage Temperature Range ............................-65°C to +150°C
Lead Temperature (soldering, 10s) ................................+300°C
ELECTRICAL CHARACTERISTICS
(V DD = +2.7 to +5.25V, GND = 0, external reference = +2.5V, output voltage = +2.0V, T A = -40°C to +85°C. Typical values are at
V DD = +3.0V, and T A = +25°C.) (Note 1)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
STATIC PERFORMANCE—ANALOG SECTION
Resolution 10 Bits
I
OUT
_ = 1.2mA ±4
Integral Nonlinearity (Note 2) INL
I OUT _ = 3.6mA ±6
LSB
Differential Nonlinearity DNL Guaranteed monotonic ±0.75 LSB
Offset Error OE Code = 030h ±4 LSB
Offset Temperature Coefficent 0.05 LSB/°C
I OUT = 1.2mA ±0.1 ±3
Gain Error GE
Measured from code
030h to 3FFh
I OUT = 3.6mA ±0.1 ±5.5
%
I OUT_ = 1.2mA 15
Gain Temperature Coefficient
I OUT_ = 3.6mA 25
ppm/°C
Line Regulation V DD = +2.7V to +5.25V 0.8 LSB/V
Output Crosstalk
OUTA = midscale, OUTB switching from
030h to 3FFh
54 dB
REFERENCE
Internal-Reference Voltage V REF T A = +25°C 2.48 2.5 2.52 V
Internal-Reference Temperature
Coefficient
(Note 3) 4 35 ppm/°C
Internal-Reference Load
Regulation
0µA < I REF < +300µA 1 3.5 Ω
Internal-Reference Power-Up
Time
C REF = 1µF, to 0.05% 0.55 ms
Internal-Reference Sink Current 50 µA
Internal-Reference Source
Current
300 µA
REF Capacitive Load (Note 3) 0.1 10.0 µF
Reference Line Regulation V
DD
= +2.7V to +5.25V 25 µV/V
f = 0.1Hz to 10Hz 10
Internal-Reference Noise
f = 10Hz to 10kHz 27
µV
RMS
External-Reference Range V REF 2.45 2.55 V
