Page 14

S2
opened
Nand write protect:
opened: write protection disabled
closed: write protection enabled
1.2. Memory
Memory configuration
Designation
Default setting
Feature
SDRAM U4 & U8
R60
R65
Soldered
Soldered
Enables U4 (D[16..31])chip select access
Enables U8 (D[0..15]) chip select access
NANDFlash U7
J15
R71
S2
closed
Soldered
Opened
Enables the use of NANDFlash
Enables the use of Ready/busy signal
Disables write protect
1.3. Miscellaneous
Designation
Default setting
Feature
R15
soldered
USB device: Enables the use of USBCNX signal.
R46
R47
R45
R19
R18
R52
R16
R17
R53
soldered
soldered
soldered
soldered
soldered
soldered
soldered
soldered
soldered
RTS0
TXD0
DTR0
DCD0
DSR0
RXD0
CTS0
RI0
Receiver outputs enabled.
Datasheet USG-00001-B01
14/28
