MAX4951
SATA I/SATA II Bidirectional Re-Driver
Maxim cannot assume responsibility for use of any circuitry other than circuitry entirely embodied in a Maxim product. No circuit patent licenses are
implied. Maxim reserves the right to change the circuitry and specifications without notice at any time.
Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 _____________________ 9
© 2009 Maxim Integrated Products
Maxim is a registered trademark of Maxim Integrated Products, Inc.
MAX4951
EN
GPIO
+3.3V
0.001
µF
0.1
µF
GND
BB
BA
+3.3V
SATA HOST
CONTROLLER
eSATA DEVICE CONNECTOR
Rx
Tx
10nF (X7R)
10nF (X7R)
10nF (X7R)
10nF (X7R)
10nF (X7R)
10nF (X7R)
10nF (X7R)
10nF (X7R)
HAP
HAM
HBM
HBP
DAP
DAM
DBM
DBP
Tx
Rx
Figure 3. Typical Application Circuit
Package Information
For the latest package outline information, go to
www.maxim-ic.com/packages
.
PACKAGE TYPE
PACKAGE CODE
DOCUMENT NO.
20 TQFN-EP
T2044-2
Chip Information
PROCESS: BiCMOS
Revision History
REVISION
NUMBER
REVISION
DATE
DESCRIPTION
PAGES
CHANGED
0
6/08
Initial release
—
1
5/09
Updated Features, Electrical Characteristics table, Applications Information
section, and added ESD Protection and Human Body Model sections.
1, 3, 6, 7, 8
