MAX5363/MAX5364/MAX5365
Low-Cost, Low-Power, 6-Bit DACs with 3-Wire
Serial Interface in SOT23
4 _______________________________________________________________________________________
-0.045
-0.020
-0.030
-0.025
-0.035
-0.040
-0.015
-0.010
-0.005
0
0.005
0.010
0.015
0.020
0.025
0.030
0 25 50 75
INTEGRAL NONLINEARITY vs. CODE
MAX5363/4/5-01
CODE
INL (LSB)
0
-0.025
-0.050
2.5 4.0 3.0 3.5 4.5 5.0 5.5
INTEGRAL NONLINEARITY
vs. SUPPLY VOLTAGE
MAX5363/4/5-02
SUPPLY VOLTAGE (V)
INL (LSB)
0
-0.025
-0.050
-40 20 -20 0 40 60 80 100
INTEGRAL NONLINEARITY
vs. TEMPERATURE
MAX5363/4/5-03
TEMPERATURE (°C)
INL (LSB)
-0.020
-0.010
-0.015
-0.005
0
0.005
0.010
0 25 50 75
DIFFERENTIAL NONLINEARITY vs. CODE
MAX5363/4/5-04
CODE
DNL (LSB)
0
-0.015
-0.020
-0.010
-0.005
-0.025
2.5 4.0 3.0 3.5 4.5 5.0 5.5
DIFFERENTIAL NONLINEARITY
vs. SUPPLY VOLTAGE
MAX5363/4/5-05
SUPPLY VOLTAGE (V)
DNL (LSB)
0
-0.010
-0.015
-0.020
-0.005
-0.025
-40 20 -20 0 40 60 80 100
DIFFERENTIAL NONLINEARITY
vs. TEMPERATURE
MAX5363/4/5-06
TEMPERATURE (°C)
DNL (LSB)
Typical Operating Characteristics
(V DD = +3.0V (MAX5363), V DD = +5.0V (MAX5364/MAX5365), T A = +25°C, unless otherwise noted.)
TIMING CHARACTERISTICS (continued)
(Figures 3 and 4, V DD = +2.7V to +3.6V (MAX5363), V DD = +4.5V to +5.5V (MAX5364), V DD = +2.7V to +5.5V (MAX5365), R L =
10k Ω, C
L = 50pF, T A = T MIN to T MAX , unless otherwise noted. Typical values are T A = +25°C.) (Note 7)
Note 1: Guaranteed from code 2 to code 63.
Note 2: The offset value extrapolated from the range over which the INL is guaranteed.
Note 3: MAX5365 tested at 5V ±10%.
Note 4: MAX5363 tested at 3V ±10%; MAX5364 tested at 5V ±10%.
Note 5: Actual output voltages at full scale are 63/64
✕ V
REF
.
Note 6: Output settling time is measured by stepping from code 2 to code 63, and from code 63 to code 2.
Note 7: Guaranteed by design.
