MAX5188/MAX5191
Dual, 8-Bit, 40MHz, Current/Voltage,
Alternate-Phase Output DACs
_______________________________________________________________________________________ 3
ELECTRICAL CHARACTERISTICS (continued)
(AV DD = DV DD = +3V ±10%, AGND = DGND = 0, f CLK = 40MHz, I FS = 1mA, 400 Ω differential output, C
L = 5pF, T A = T MIN to T MAX ,
unless otherwise noted. Typical values are at T A = +25°C.)
CS Fall to CLK Fall Time 5 ns
DACEN Rise Time to V OUT 0.5 µs
PD Fall Time to V OUT 50 µs
Clock Period t CLK 25 ns
Clock High Time t
CH
10 ns
Clock Low Time t CL 10 ns
PARAMETER SYMBOL MIN TYP MAX UNITS
Current Gain (I FS / I REF ) 8 mA/mA
Reference Supply Rejection 0.5 mV/V
Reference Output Drive
Capability
I REFOUT 10 µA
Analog Power-Supply Voltage AV DD 2.7 3.3 V
Analog Supply Current I AVDD 2.7 5 mA
Digital Power-Supply Voltage DV
DD
2.7 3.3 V
Digital Supply Current I DVDD 4.2 5 mA
Output Voltage Range V REF 1.12 1.2 1.28 V
Output Voltage Temperature
Drift
TCV
REF
50 ppm/°C
Standby Current I STANDBY 1 1.5 mA
Shutdown Current I SHDN 0.5 1 µA
Digital Input High Voltage V
IH
2 V
Digital Input Low Voltage V IL 0.8 V
Digital Input Current I IN ±1 µA
Digital Input Capacitance C IN 10 pF
DAC1 DATA to CLK Rise Setup
Time
t DS1 10 ns
DAC2 DATA to CLK Fall Setup
Time
t
DS2
10 ns
DAC1 CLK Rise to DATA Hold
Time
t
DH1
0 ns
DAC2 CLK Fall to DATA Hold
Time
t DH2 0 ns
CS Fall to CLK Rise Time 5 ns
CONDITIONS
PD = 0, DACEN = 0, digital inputs at 0 or DV DD
PD = 1, DACEN = X, digital inputs at 0 or DV DD
(X = don’t care)
PD = 0, DACEN = 1, digital inputs at 0 or DV DD
PD = 0, DACEN = 1, digital inputs at 0 or DV DD
V IN = 0 or DV DD
REFERENCE
POWER REQUIREMENTS
LOGIC INPUTS AND OUTPUTS
TIMING CHARACTERISTICS
Note 1: Excludes reference and reference resistor (MAX5191) tolerance.
