MAX5152/MAX5153
Low-Power, Dual, 13-Bit Voltage-Output DACs
with Configurable Outputs
4 _______________________________________________________________________________________
ELECTRICAL CHARACTERISTICS—MAX5153
(V DD = +2.7V to +3.6V, V REFA = V REFB = 1.25V, R L = 10k
Ω
, C L = 100pF, T A = T MIN to T MAX , unless otherwise noted. Typical values
are at T A = +25°C, output buffer connected in unity-gain configuration (Figure 9).)
V IN = 0V to V DD
CL, PDL, CS, DIN, SCLK
CL, PDL, CS, DIN, SCLK
Input code = 1FFF hex,
V
REF = 1Vp-p at 1.25V DC , f = 15kHz
Input code = 0000 hex,
V
REF = (V DD - 1.4V) at 1kHz
2.7V
≤
V DD
≤
3.6V
Input code = 1FFF hex,
V
REF(AC) = 0.67Vp-p at 1.25V DC
Normalized to 1.25V
(Note 5)
Guaranteed monotonic
Code = 40
Minimum with code 1555 hex
Normalized to 1.25V
CONDITIONS
pF 8 C IN Input Capacitance
µA 0 ±0.1 I IN Input Leakage Current
mV 200 V HYS Input Hysteresis
V 0.8 V IL Input Low Voltage
V 2.2 V IH Input High Voltage
dB 73 SINAD
Signal-to-Noise plus
Distortion Ratio
dB -92 Reference Feedthrough
kHz 600 Reference 3dB Bandwidth
k
Ω
14 R REF Reference Input Resistance
V 0
V DD -
1.4
REF Reference Input Range
±1
Bits 13 N Resolution
µV/V 20 320 PSRR
V DD Power-Supply
Rejection Ratio
ppm/°C 6 Gain-Error Tempco
LSB -0.5 ±8 Gain Error
LSB
±2
INL Integral Nonlinearity
LSB ±1 DNL Differential Nonlinearity
mV ±6 V OS Offset Error
ppm/°C 6 TCV OS Offset Tempco
UNITS MIN TYP MAX SYMBOL PARAMETER
MAX5153A
MAX5153B
I SINK = 2mA
I SOURCE = 2mA
V 0.13 0.4 V OL Output Low Voltage
V V DD - 0.5 V OH Output High Voltage
STATIC PERFORMANCE
REFERENCE INPUT (V REF )
MULTIPLYING-MODE PERFORMANCE
DIGITAL INPUTS
DIGITAL OUTPUTS (DOUT, UPO)
