Rainbow Electronics MAX16999 User Manual
Page 7
MAX16999
Ultra-Low Output Voltage, Low-Quiescent-Current
Linear Regulator for High-Temperature Applications
_______________________________________________________________________________________
7
_______________________________________________________________________________________
7
IN
ERROR
AMPLIFIER
V
REF
0.825 x V
REF
V
CRES,THRS
100k
Ω
OUT
CRES
EP
RESET
EN
GND
MAX16999
POR
COMPARATOR
CRES
COMPARATOR
20
μs
DEGLITCH
LOGIC
CONTROL
I
CRES,UP
(10
μA)
I
CRES,DOWN
(10mA)
COUNTER
(100ms)
Figure 1. Block Diagram
