MX7837/MX7847
Complete, Dual, 12-Bit
Multiplying DACs
C
A
E
D
E1
B1
B
DIM
A
B
B1
C
D
E
E1
e
L
L1
Q
S
S1
α
MIN
–
0.014
0.038
0.008
–
0.220
0.290
0.125
0.150
0.015
–
0.005
0˚
MAX
0.200
0.023
0.065
0.015
1.280
0.310
0.320
0.200
–
0.060
0.098
–
15˚
MIN
–
0.36
0.97
0.20
–
5.59
7.37
3.18
3.81
0.38
–
0.13
0˚
MAX
5.08
0.58
1.65
0.38
32.51
7.87
8.13
5.08
–
1.52
2.49
–
15˚
INCHES MILLIMETERS
2.54 BSC 0.100 BSC
Q
L
S1
e
21-340B
24-PIN CERAMIC
DUAL-IN-LINE
(NARROW)
PACKAGE
α
S
L1
___________________________________________Package Information (continued)
