MAXQ1004
1-Wire and SPI Authentication Microcontroller
5
RECOMMENDED DC OPERATING CONDITIONS (continued)
(V DD = 1.7V to 3.6V, T A = -40NC to +85NC, unless otherwise noted. Typical values are at T A = +25NC and V DD = 3.3V, unless oth-
erwise noted.) (Note 1)
10-BIT ADC PERFORMANCE
(V DD = 1.7V to 3.6V, V REF = 1.845V, T A = -40NC to +85NC, unless otherwise noted.)
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
INTERNAL OSCILLATOR
Oscillator Frequency
f OSC 5 6 7 MHz
Oscillator Startup Time t OSC_RDY V REG18 = 1.8V (Note 6) 350 F s
Oscillator Duty Cycle (Note 6) 45 55 %
NANOPOWER RING OSCILLATOR
Nanopower Ring Frequency
f NANO T A = +25NC 3 11 22 kHz
Nanopower Ring Current I NANO
Typical at V
DD
= 3.0V, active
during wake-up (Note 6)
120 400 nA
Wakeup Timer Interval t WAKEUP 1/f NANO t NANO
65,535
x t NANO
s
FLASH MEMORY
Flash Erase Time
Mass erase 20 40
ms
Page erase 20 40
Flash Programming Time per Word t PROG 20 40
F
s
Write/Erase Cycles 1000 Cycles
Data Retention T A = +25NC 100 Years
Analog Supply Voltage V AVDD V DD V
PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS
Resolution 10 Bits
ADC Clock Frequency f ACLK f SYSCLK MHz
ADC Clock Period t ACLK 1/f ACLK F s
AN0 Input Voltage Range V AN0 V GND V AVDD V
Analog Input Capacitance C AIN 1 pF
Integral Nonlinearity INL (Note 6)
Q
2 LSB
Differential Nonlinearity DNL No missing codes over temperature
Q 1 LSB
Offset Error V OS Q 2 LSB
ADC Active Current Consumption I ADC
ACLK = 6MHz, internal reference
on, ADEN = 1 (Note 6)
100 150 F A
ADC Setup Time t ADC_SETUP 25
F
s
ADC Output Latency t ADC 1025 t ACLK
ADC Settling Time t ADC_SETTLE
Settling time due to channel, refer-
ence or scale change (not produc-
tion tested)
10 F s
ADC Throughput f ADC f ADC /t ADC ksps
TEMPERATURE SENSOR
Temperature Sensor Setup Time
t TSN_SETUP 25 F s
Temperature Sensor Error D TSN Q 6 N C
