MAXQ1004
1-Wire and SPI Authentication Microcontroller
17
Package Information
For the latest package outline information and land patterns, go to www.maxim-ic.com/packages . Note that a “+”, “#”, or “-” in the
package code indicates RoHS status only. Package drawings may show a different suffix character, but the drawing pertains to the
package regardless of RoHS status.
Figure 4. Typical Application Circuit
MAXQ1004
DQ
V DD
AVDD
REG18 GND
AN0
150Ω
1kΩ
100nF 1µF
PROTECTOR
FACTORY-ISSUE
ORIGINAL BATTERY PACK
PACK+
1-Wire
PACK-
PACKAGE TYPE PACKAGE CODE DOCUMENT NO.
16 TQFN-EP T1644+4 21-0139
