Slave Functionality
The 1-Wire slave provides three functions. The first is
that of a totally independent slave function, which can
be externally accessed at any time to verify its identity.
The 1-Wire front-end functions in an identical fashion to
that of the DS1990 serial ID to verify the serial ID number.
The bus master must provide one of the ROM function
commands:
• Read ROM
• Match ROM
• Search ROM
• Skip ROM
• Overdrive-Skip ROM
• Overdrive-Match ROM
• Resume
The second function is that of a 1-Wire that includes full
bidirectional data flow and data flow control. The 1-Wire
functions that become accessible after a ROM function
command is successfully executed initiate communica-
tions with the microcontroller through the use of specific
1-Wire commands:
• Read I/O Buffer
• Write I/O Buffer
• Read Command Buffer
• Write Command Buffer
• Read Command Buffer Extended
• Write Command Buffer Extended
• Status Register Read
• Status Register Write
The third function controls the operation of the 1-Wire
interface:
• 1-Wire Micro Reset
And the remaining are 1-Wire run commands:
• Start Program
• Continue Program
• Write Command Buffer Extended and Start Program
• Write Command Buffer Extended and Continue Program
Operating Modes
The low-power mode of operation is stop mode. In this
mode, CPU state and memories are preserved, but the
CPU is not actively running. Wake-up sources include
external I/O interrupts, the power-fail warning interrupt,
a valid 1-Wire command received, or a power-fail reset.
Any time the microcontroller is in a state where code
does not need to be executed, the user software can
enter stop mode.
An even lower stop mode is the data-retention mode,
in which the CPU is not active. When the data-retention
mode option is invoked (DRET = 1) and the regula-
tor is disabled (REGEN = 0), only the first 512 bytes
of data memory is retained (data memory word offset
0000h–00FFh). CPU status and 1-Wire/AES memory are
powered down and contents are lost. A POR occurs
when exiting stop mode from data-retention mode. This
mode can be exited from any of the following enabled
interrupt sources:
• Enabled external interrupts
• External reset
• Enabled PFW interrupt
• Valid 1-Wire command received
• Wake-up timer
The wake-up timer causes the device to exit stop mode
after a user-selectable time period. The power-fail moni-
tor is always on during normal operation. However, it can
be selectively disabled during stop mode using the pow-
er-fail monitor disable (PFD) bit in the PWCN register. By
default, the power-fail monitor function is enabled during
stop mode. If power-fail monitoring is disabled (PFD = 1)
during stop mode, the circuitry responsible for generat-
ing a power-fail warning or reset is shut down and neither
condition is detected. Thus, the V
DD < V RST condition
does not invoke a reset state. However, in the event that
V
DD falls below the POR level, a POR is generated. The
power-fail monitor is enabled prior to stop mode exit and
before code execution begins. If a power-fail warning
condition (V
DD < V PFW ) is then detected, the power-fail
interrupt flag is set on stop mode exit. If a power-fail con-
dition is detected (V
DD < V RST ), the CPU goes into reset.
The 1-Wire peripheral can operate in a special mode
that draws minimal power, yet can serve as a wake-
up source to bring the device out of stop mode. If the
1-Wire peripheral is required to run in stop mode, it can
be enabled so a regular 1-Wire reset pulse briefly wakes
up the 1-Wire controller. The 1-Wire controller then deter-
mines if it was addressed. If so, the 1-Wire controller
wakes up the CPU from stop mode. If the microcontroller
is not being addressed, then stop mode continues and
the 1-Wire controller is powered down again, and the
device returns to its lowest power state. The device does
not respond to an overdrive reset pulse in stop mode.
