MAX6678

2-Channel Temperature Monitor with Dual Automatic
PWM Fan-Speed Controller and Five GPIOs

2

_______________________________________________________________________________________

ABSOLUTE MAXIMUM RATINGS

ELECTRICAL CHARACTERISTICS

(V

CC

= +3.0V to +5.5V, T

A

= -40°C to +125°C, unless otherwise noted. Typical values are at V

CC

= +3.3V, T

A

= +25°C.)

Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings only, and functional
operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to
absolute maximum rating conditions for extended periods may affect device reliability.

V

CC

to GND ..............................................................-0.3V to +6V

OT, SMBDATA, SMBCLK, PWMOUT_,

GPIO_ to GND ......................................................-0.3V to +6V

DXP_ to GND ..........................................-0.3V to + (V

CC

+ 0.3V)

DXN to GND ..........................................................-0.3V to +0.8V
PRESET_ to GND ....................................-0.3V to + (V

CC

+ 0.3V)

SMBDATA,

OT, PWMOUT_ Current....................-1mA to +50mA

DXN Current .......................................................................±1mA
ESD Protection (all pins, Human Body Model) ..................2000V

Continuous Power Dissipation (T

A

= +70°C)

20-Pin QSOP (derate 9.1mW/°C above +70°C).......... 727mW
20-Pin TQFN (derate 34.5mW/°C above +70°C) .......2759mW

Operating Temperature Range .........................-40°C to +125°C
Junction Temperature ......................................................+150°C
Storage Temperature Range ............................-65°C to +150°C
Lead Temperature (soldering, 10s) .................................+300°C

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Operating Supply Voltage Range

V

CC

+3.0

+5.5

V

Operating Current

I

S

Interface inactive, ADC active

0.5

1

mA

+25°C

≤ T

R

≤ +125°C,

T

A

= 60°C

±1

V

CC

= 3.3V

0°C

≤ T

R

≤ +145°C,

+25°C

≤ T

A

≤ +100°C

±3

External Temperature Error,
V

CC

= 3.3V

0°C

≤ T

R

≤ +145°C,

0°C

≤ T

A

≤ +125°C

±4

°C

+25°C

≤ T

R

≤ +100°C

±2.5

Internal Temperature Error

V

CC

= +3.3V

0°C

≤ T

A

≤ +125°C

±4

°C

1

°C

Temperature Resolution

8

Bits

Conversion Time

200

250

300

ms

PWM Frequency Tolerance

(Note 1)

-20

+20

%

High level

80

100

120

Remote-Diode Sourcing Current

Low level

8

10

12

µA

DXN Source Voltage

0.7

V

DIGITAL INPUTS AND OUTPUTS

Output Low Voltage (Sink Current)
(

OT, GPIO_, SMBDATA, PWMOUT_)

V

OL

I

OUT

= 6mA

0.4

V

Output High Leakage Current
(

OT, GPIO_, SMBDATA, PWMOUT_)

I

OH

1

µA

V

CC

= 3V to 3.6V

0.8

Logic-Low Input Voltage (SMBDATA,
SMBCLK, PRESET_, GPIO_)

V

IL

V

CC

= 3.6V to 5.5V

0.8

V

V

CC

= 3V to 3.6V

2.1

Logic-High Input Voltage (SMBDATA,
SMBCLK, PRESET_, GPIO_)

V

IH

V

CC

= 3.6V to 5.5V

2.1

V

Input Leakage Current

1

µA

Input Capacitance

C

IN

5

pF

SMBus TIMING

Serial Clock Frequency

f

SCLK

100

kHz
