1
Technical Specifications
1-18 9067 PRODUCT MANUAL 9067-OM (V4.4)
Technical Specifications
Table 1-3 lists the technical specifications for the 9067 Upconverter with
SD-SDI Input, Embedded Audio, Frame Sync, Timecode and Closed Caption
Support card.
Table 1-3 Technical Specifications
Item Characteristic
Part number, nomenclature 9067 Upconverter with SD-SDI Input, Embedded Audio, Frame
Sync, Timecode and Closed Caption Support
Installation/usage environment Intended for installation and usage in frame meeting openGear™
modular system definition.
Power consumption < 18 Watts maximum
Environmental:
Operating temperature:
Relative humidity (operating or storage): 32° – 104° F (0° – 40° C)
< 95%, non-condensing
Frame communication 10/100 Mbps Ethernet with Auto-MDIX.
Indicators Card edge display and indicators as follows:
• 4-character alphanumeric display
• Status/Error LED indicator
• Input Format LED indicator
Controls Card edge switches as follows:
• Menu Enter pushbutton switch
• Menu exit pushbutton switch
• Up/down selection toggle switch
Internal Tone Generators Four built-in tone generators, each configurable for 18 discrete
sine wave frequencies ranging from 50 Hz to 16 kHz.
Generator source signal level is equivalent to -20 dBu.
Serial Digital Video Input Data Rates Supported:
SMPTE 259M-C SD-SDI: 270 Mbps
Impedance:
75 Ω terminating
Equalization:
1000 ft (305 m) Belden 1694A
Return Loss:
> 15 dB at 5 MHz – 1.485 GHz
Audio/RS-485 LTC Support
(+LTC option only) Balanced analog audio or AES/embedded PCM equivalent
conforming to SMPTE 12M-1; § 9.6; RS-485 LTC
Dolby ® RS485 Metadata Output Metadata extracted from input video (per SMPTE 2020-1-2008) on
RS-485 interface; 3-wire balanced via Phoenix terminal block
connector.
