15
REMOTE CONTROL
DashBoard Control
This card may be monitored or controlled by a remote computer through DashBoard the free
configuration monitoring software available to openGear users.
With DashBoard installed on your computer the following menus are available when
interrogating a 9253 card:
MENU ITEM DISPLAY DESCRIPTION
Product 9253 Product identification code
Name Dual Unbalanced AES Distribution
Amplifier Product functional description
Supplier Cobalt Digital Inc. Manufacturer of the card
Software Rev. ## Three digit software revision code
Card Info
(Read
Only)
Web site www.cobaltdigital.com Manufacturer’s web address
MENU ITEM DISPLAY DESCRIPTION
Green Dot - OK Card is functioning properly and
appropriate signals are connected Card
Status
Red Dot – No AES signal detected AES signal is not present at either
input
Locked AES signal is present AES Input 1
Unlocked AES signal is not present
Locked AES signal is present
Card
Status
(Read
Only)
AES Input 2
Unlocked AES signal is not present
MENU ITEM BUTTON SELECTION DESCRIPTION
1 x 8 Functions as a 1 in 8 out AES DA
1 x 4 Functions as dual 1 in 4out AES DA
Card
Settings
(Button
selection)
Mode
1 x 8 w/SRC Functions as a 1 in 8 out AES DA with
Sample Rate Conversion.
A sampling signal must be connected
to AES input 2 or jumpers on card
may be set to select between AES2 or
frame reference 1 or 2
