9323G-OM (V4.6) 9323 GROUP PRODUCT MANUAL 1-1
Chapter 1
Chapter 1
Introduction
Overview
This manual provides installation and operating instructions for the
9323 group of HD/SD Video Proc and Embedder/De-Embedders with Dolby
®
Decoding cards (also referred to herein as the 932X or “card”).
Note: This manual covers the 9323 group, which consists of the 9323, 9322, and
9321 cards. These cards vary only in audio embedding/de-embedding capa-
bilities; the differences are described in detail later in this section.
All of the 9323 group cards are available with Dolby ® decoding as an option.
Cards equipped with this option are identified by suffix “+DEC” in both part
numbers and this manual. Where applicable, descriptions related exclusively
to the either the 932X or the 932X+DEC are respectively denoted by
(932X only) or (932X+DEC only). In all other aspects, both the 932X and
932X+DEC cards function identically as described in this manual.
This manual consists of the following chapters:
• Chapter 1, “Introduction” – Provides information about this manual
and what is covered. Also provides general information regarding the
932X group.
• Chapter 2, “Installation and Setup” – Provides instructions for
installing this card in a frame, and optionally installing Rear I/O
Modules.
• Chapter 3, “Operating Instructions” – Provides overviews of
operating controls and instructions for using this card.
This chapter contains the following information:
• 932X Card Software Versions and this Manual (p. 1-2)
• Manual Conventions (p. 1-3)
• Safety Summary (p. 1-4)
• 932X Functional Description (p. 1-5)
• Technical Specifications (p. 1-21)
• Warranty and Service Information (p. 1-24)
• Contact Cobalt Digital Inc. (p. 1-25)
