of change of Delay time by all controls (Delay Time control, Delay Time CV,
LFO, and MIDI control of Delay time). Larger values slow down the rate of
change, creating a “glide” effect for the Delay time.The default value on
each power cyle is 0
CC# 7 (MSB)/ CC#39 (LSB): Output Level Control
CC# 12 (MSB)/ CC#44 (LSB): Delay Time
CC# 13 (MSB)/ CC#45 (LSB): Feedback
CC# 14 (MSB)/ CC#46 (LSB): Mix Control
CC# 15 (MSB)/ CC# 47 (LSB): LFO Rate
CC# 16 (MSB)/ CC# 48 (LSB): LFO Amount
CC# 70: LFO Waveform (0-15=Sine, 16-31=Triangle, 32-47=Square, 48-63=Saw,
64-79=Ramp, 80-95=Random Stepped, 96-127=Smoothed Random (Not
available on Front panel))
CC# 74: Range (Flange/Chorus) (0-63=Flange, 64-127=Chorus)
CC# 91: Bypass On/Off (0-63=Effect Off 64-127=Effect On)
THE FOLLOWING CC MESSAGES DO NOT CORRESPOND TO FRONT
PANEL CONTROLS, BUT EXTEND THE CLUSTER FLUX’S CAPABILITIES.
The Delay Time Range Multiplier multiplies the delay time by 2, 4 or 8
vastly extending delay time. This feature is for obtaining unusual/ lo-fi
echo effects. When the delay time is increased past the default maximum
delay time available on the front panel, the BBD Clock signal will be audible
CC# 71: LFO Clock Divisions. Here is a list of values and associated rhythmic
divisions achieved with this CC.
CC# 72: LFO Phase Reset- Sending any value of this CC message will restart
the LFO from the beginning of its waveform.
CC# 73: Enable LFO Note Reset (0=Disabled, 64=Enabled) Enable or disable
the restarting of the LFO from the beginning of its waveform when the unit
CC71 VALUE CLOCK DIVISION CC71 VALUE CLOCK DIVISION
0-5 4 Whole Notes 64-69 1/2 Triplet
6-11 3 Whole Notes 70-75 1/4 Note
12-17 2 Whole Notes 76-81 Dotted 1/8
18-23 WH+Dotted 1/2 82-87 1/4 Triplet
24-29 Dotted Whole 88-93 1/8 Note
30-34 Whole + 1/4 94-98 Dotted 1/16
35-40 Whole Note 99-104 1/8 Triplet
41-46 Dotted 1/2 105-110 1/16 Note
47-52 Whole Triplet 111-116 1/16 Triplet
53-58 1/2 Note 117-122 1/32 Note
59-63 Dotted 1/4 123-127 1/32 Triplet
