Ergonomic Flooring Installation Guide:
BEFORE YOU BEGIN
Area Preparation
Prepare the Floor
Required Tools
Optional Cutting Tools
Optional Supplies
This product is recommended for interior, mostly dry areas of heavy traffick and usage.
It is recommended to sweep the surface of dust and debris before beginning.
2
Utility knife or industrial shears
Leather or Kevlar ® gloves
Measuring tape
Straight edge
Super glue (for permanent installations)
Skil ® saw
Band saw
RECOMMENDED:
Wear protective gloves when
using a cutting tool or
handling products with a
grit surface. We recommend
leather or Kevlar ® gloves.
Product Overview
Each ergonomic flooring product is uniquely designed for a totally flexible floor layout design. Below is a brief description of each available ergonomic flooring product and
information regarding its construction.
Rejuvenator ® ErgoDeck ® F.I.T.™ Functional Interlocking Tiles
Rejuvenator is the ultimate ergonomic floor in terms of
comfort and construction.
Large modular tiles interlock on all four sides to
customize on-site virtually any flooring configuration.
Interlocking ends and centers are also available to quickly
and easily fabricate long runners.
These runner components have built in borders that
eliminate the need for separate edging and reduces costs
and installation time.
Each Rejuvenator Tile has:
Nine (9) male connectors on two adjacent sides.
Nine (9) corresponding, hidden female connectors on the
other two sides.
A comfortable, ergonomic floor that will withstand heavy
use.
Tiles can be unlocked and repositioned as work centers
change to fit your needs.
Optional 6” side safety ramps and corners are available.
Solid and drainage designs offered in 3 comfort levels: Heavy
Duty (heavy use) and General Purpose (more comfort and
light cart traffic) and Comfort (for optimum relief for foot
traffic.) For optimum traction choose one of our 2 versions
with No-Slip Cleats.
Each ErgoDeck Tile has:
Six (6) female LockSafe connectors on two adjacent sides.
Six (6) corresponding, hidden male connectors on the other
two sides.
The most versatile 12” x 12” and 100% Silicone-free
interlocking ergonomic flooring system in the market.
Tiles snap together and configure to fit your workspace.
The top surface and underside of F.I.T. tiles are designed to
allow rapid drainage of fluids.
F.I.T. tiles stay together very well making them ideal as a liner
for mobile tool storage bins that require frequent removal
for cleaning purposes.
Each F.I.T.™ Tile has:
Four (4) female LockSafe connectors on two adjacent sides.
Four (4) corresponding, hidden male connectors on the
other two sides.
3 countersunk
holes for
permanent
installations.
1/16” thick
friction bars.
18”
Outside Corner
Ramp
18”
18”
6” 6”
Patented LockSafe®
interlocking system for a
positive connection.
Slanted surface facilitates drainage.
15”
12”
12”
3”
Female Ramp
Male Ramp
