Wilwood • June 2009 • 805 / 388-1188 • Fax 805 / 388-4938 • www.wilwood.com
2.56 (65,0)
MOUNT
HEIGHT
"D1"
TOP OF FRICTION MATERIAL
AND DISC O.D. TO BE FLUSH
SMALL
PISTON SMALL
PISTON
.52 (13,2)
13.16 (334,3)
"C"
OVERALL WIDTH
LARGE
PISTON
DISC WIDTH
2.02 (51,3) 2.02 (51,3)
"B"
MOUNT OFFSET
"E"
OUTSIDE RADIUS
8.27 (210,1)
MOUNT CENTER
DISC/WHEEL CENTERLINE
DIMENSIONS "D1" = (DISC DIAMETER/2) - 2.56 (65,0)
NOTE:
RIGHT HAND REAR MOUNT CALIPER SHOWN
INLET FITTING: 1/8-27 NPT
DISC ROTATION
DISC
DIAMETER
16.00 (406,4)
14.00 (355,6)
"E"
OUTSIDE RADIUS
8.81 (223,8)
8.14 (206,8)
"C"
OVERALL WIDTH
5.41 (137,4)
5.29 (134,4)
DISC
WIDTH
1.38 (35,1)
1.25 (31,8)
"B"
MOUNT OFFSET
1.65 (41,9)
1.59 (40,3)
6 PISTON
BILLET TC 6 CALIPER, MOUNTING DIMENSIONS:
2.74 (69,6)
6.40 (162,6) .71
(18,0)
AXLE SET PART NO. PAD TYPE/COMPOUND
15Q- 8823K 6318 Q PolyMatrix
150 - 9118K 6318 10 BP-10
TC 6 CALIPER, TYPE 6318 PAD DIMENSIONS AND ORDERING INFORMATION:
ORDERING INFORMATION, USER SERVICEABLE COMPONENTS:
CALIPER SQ RING BLEED SCREW CROSSOVER BRIDGE BRIDGE WEAR
PART NO. PISTON KIT (6 PK) KIT (4 PK) TUBE KIT (4 PK) BOLT KIT PLATE (EA)
120-8907 200-7528 (1.75”) 130-3084 220-6069 190-9172 230-9171 300-8893 (R/H)
200-7518 (1.38”) 300-8894 (L/H)
120-8908 200-7528 (1.75”) 130-3084 220-6069 190-9172 230-9171 300-8893 (R/H)
200-7518 (1.38”) 300-8894 (L/H)
120-8909 200-9060 (1.88”) 130-9173 220-6069 190-9172 230-9171 300-8893 (R/H)
200-7520 (1.62”) 300-8894 (L/H)
120-8910 200-9060 (1.88”) 130-9173 220-6069 190-9172 230-9171 300-8893 (R/H)
200-7520 (1.62”) 300-8894 (L/H)
120-9138 200-7520 (1.62”) 130-5972- 220-6069 190-9201 230-9200 300-8893 (R/H)
200-8439 (1.12”) 300-8894 (L/H)
120-9139 200-7520 (1.62”) 130-5972 220-6069 190-9201 230-9200 300-8893 (R/H)
200-8439 (1.`2”) 300-8894 (L/H)
