General Information
Parts List
Installation of this kit should ONLY be performed by persons experienced in the installation and proper operation of disc brake systems.
Before assembling the Wilwood front disc brake kit, double check the following items to ensure a trouble-free installation. Also, please read
these instructions thoroughly to be sure you have a complete understanding of the procedure involved before work is begun.
•Make sure this is the correct kit to match the exact make and model year of the vehicles spindle (i.e., hubs for a 1960 Ford spindle will
not fit a 1973 Ford spindle).
•Verify the hub stud pattern in this kit matches the stud pattern of the vehicles wheels. There are two (5 x 4.50” and 5 x 4.75”) bolt circle
patterns. The one applicable to this kit is the one with the smaller 5 x 4.50” stud pattern.
•Verify your wheel clearance using Figure 2.
•Inspect the package contents against the parts list (below) to ensure that all components and hardware are included.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
2
1
2
4
2
2
10
2
2
2
2
2
16
16
6
2
2
2
2
2
4
4
249-9483/84
150-8855K
230-9531
240-11102
230-9458
240-11101
230-6959
270-9486
370-0884
380-0885
160-11839/40
170-8320
240-1848
230-11935
230-10419
370-0882
240-2444
211-1674
270-9380D
120-11136
230-10023
230-11101 Bracket Kit, Caliper Mounting (left and right)
Pad, BP-10, Axle Set
Bolt, 1/2-13 x 2.00 Long, Hex, Head
Washer, .515 I.D. x .875 O.D. x .063 Thick
Bolt, 7/16-14 x 1.50 Long, Hex Head
Washer, .453 I.D. x .750 O.D. x .063 Thick
Stud, 1/2-20 x 2.00 Long, 12 Point
Hub Assembly
Cone, Inner Bearing
Seal, Grease
Rotor, GT 1.25” Thk x 12.19” Dia, 8 x 7.00” Bolt Circle (left and right)
Hat, (2) 5 x 4.50”, .935” offset, 8 x 7.00” Bolt Circle
Shim, .030 Thick
Bolt, 5/16-18 x 1.00 Long, Torx Button Head
Bolt, 1/4-20 x .50 Long, Flat Head
Cone, Outer Bearing
Washer, 7/8 Spindle
O-ring
Cap, Dust
Caliper, Forged Superlite
Bolt, 7/16-20 x 1.75 Long, Flat Head
Washer, .453 I.D. x .750 O.D. X .063 Thick
ITEM NO. PART NO. DESCRIPTION QTY
NOTES:
Part Number 230-9532 Bolt Kit, caliper mounting bracket to spindle, includes part numbers 230-9531, 230-9458, 240-11102 & 240-11101
Part Number 230-12177 Bolt Kit, rotor to hat, includes part numbers 230-11935
Part Number 230-7032 Bolt Kit, hub to hat, includes part number 230-10419
Part Number 230-7031 Bolt Kit, caliper to bracket, includes part numbers 230-10023, 240-11101 and 240-1848
Wilwood offers an optional Braided Stainless Steel Hose Kit. Order part number 220-9481 (not included in kit)
Page 3
Disassembly Instructions
Disassembly Instructions:
•Disassemble the original equipment front brakes:
Raise the front wheels off the ground and support the front suspension according to the vehicle manufacturer’s instructions.
Disconnect the brake hoses from the brake line at the body. Insert a plug or fitting to prevent excessive fluid leakage during
installation. Remove caliper from OEM bracket and remove the caliper assembly along with the pads. Remove the center cap, cotter
pin, nut lock and the wheel bearing nut and washer. Remove brake rotor and hub assembly. Remove the three dust plate bolts then
remove the dust plate from the spindle (dust plate will not be reused). Remove the OEM caliper bracket from the spindle by removing
the top and bottom bolts.
