Sales and marketing bulletin

4700 Calle Bolero
•
Camarillo, CA 93012
•
www.wilwood.com
•
Sales: (805) 388-1188
•
E-mail Tech Assistance:
Combination Proportioning Valve
Mounting Bracket Kit
Kit Highlights:
•
Wilwood finally has an elegant answer to
the question, “Where do I mount my
Combination Proportioning Valve?” with
their new Mounting Bracket Kit.
•
Specifically
designed
to
work
in
conjunction with Wilwood Aluminum
Tandem Master Cylinders (P/N’s 260-
8555, 260-8556 or 260-9439), in manual
or boosted system applications.
•
Stainless steel fluid tubes are precision
bent with preinstalled stainless tube nuts
for a simple bolt-on installation between
the Combination Proportioning Valve and
the Wilwood Tandem Master Cylinder.
•
Stainless steel button head fasteners
thread into the black e-coated bracket for
a simple installation and years of durable,
rust-free performance.
•
There are two kits available. The Retrofit
Mounting Bracket Kit includes the bracket,
fluid tubes, mounting hardware and
spacers. The complete Mounting Bracket
Kit includes all the mounting hardware,
plus a Combination Proportioning Valve,
260-11179.
Combination Proportioning Valve Mounting Bracket Retrofit Kit
To Download High Resolution
326 REV DATE: 07-0213
Sales and Marketing Bulletin
Combination Proportioning Valve Installed with Mounting Bracket Kit
To Download High Resolution
ORDERING INFORMATION:
PART NUMBER
220-13189
260-13190
DESCRIPTION
Retrofit Mounting Bracket Kit
Mounting Bracket Kit with Combination Proportioning Valve
