Wilwood Dynapro Dust-Boot - Manual (Page 2)

Wilwood • April 2010 • 805 / 388-1188 • Fax 805 / 388-4938
DIMENSION "D1" =
(DISC DIAMETER/2) - 2.07 (52,6)
INLET FITTING: 1/8-27 NPT
DISC/WHEEL CENTERLINE
"B"
MOUNT OFFSET
"D1"
2.07 (52,6)
MOUNT HEIGHT
.39 (9,9)
MOUNT HOLE
TOP OF FRICTION MATERIAL
AND DISC O.D. TO BE FLUSH
DISC WIDTH
1.67
(42,4) 1.67
(42,4)
5.25 (133,4)
MOUNT CENTER
7.01 (178,1)
"E"
OUTSIDE
RADIUS
"A"
BOLT CIRCLE RADIUS
3.93 (99,8)
4.12 (104,6)
4.22 (107,2)
4.32 (109,7)
4.50 (114,3)
4.63 (117,6)
4.81 (122,2)
DISC
DIAMETER
10.00 (254,0)
10.50 (266,7)
10.75 (273,1)
11.00 (279,4)
11.44 (290,6)
11.75 (298,5)
12.19 (309,6)
"E"
OUTSIDE RADIUS
6.02 (152,9)
6.23 (158,2)
6.34 (161,0)
6.44 (163,6)
6.63 (168,4)
6.76 (171,7)
6.97 (177,0)
DISC WIDTH
.38 (9,7)
.50 (12,7)
.81 (20,6)
1.00 (25,4)
1.25 (31,8)
"B"
MOUNT OFFSET
.76 (19,3)
.82 (20,8)
.98 (24,9)
1.08 (27,4)
1.20 (30,5)
"A"
BOLT CIRCLE RADIUS
PISTON PISTON
DYNAPRO CALIPER, MOUNTING DIMENSIONS:
2.21 (56,0)
.49
(12,4) 3.96 (100,6)
DYNAPRO CALIPER, TYPE 7812 PAD DIMENSIONS AND ORDERING INFORMATION:
ORDERING INFORMATION, USER SERVICEABLE COMPONENTS:
CALIPER DUST SQ RING BLEED SCREW BODY SEAL BRIDGE WEAR PAD RETAINER
PART NO. PISTON BOOT (4 PK) KIT (4 PK) (EA) PLATE (EA) CLIP PIN (EA)
120-11481 200-11483 (1.38”) 210-7210 130-2658 220-0627 210-2582 300-5875 300-9636
120-11482 200-11484 (1.75”) 210-7210 130-2655 220-0627 210-2582 300-5875 300-9636
AXLE SET P/N PAD TYPE / COMPOUND
15A - 9835K 7812 A PolyMatrix
15B - 9836K 7812 B PolyMatrix
15E - 9837K 7812 E PolyMatrix
15H - 10644K 7812 H PolyMatrix
15Q - 10385K 7812 Q PolyMatrix
150 - 9136K 7812 10 BP-10 Smart Pad
150 - 9418K 7812 20 BP-20 Smart Pad
150 - 10020K 7812 CMFor Titanium Rotor
