Wilwood • December 2001 • 805 / 388-1188 • Fax 805 / 388-4938 • www.wilwood.com
DISC
DIAMETER
11.75 (298,5)
12.19 (309,6)
12.72 (323,1)
12.88 (327,2)
13.00 (330,2)
"E"
OUTSIDE RADIUS
6.65 (168,9)
6.81 (173,0)
7.00 (177,8)
7.07 (179,6)
7.13 (181,1)
DISC
WIDTH
1.25 (31,8)
"B"
MOUNT OFFSET
1.80 (45,7)
DIMENSION "D1" =
(DISC DIAMETER/2) - 1.62 (41,1)
NOTE: RIGHT HAND REAR MOUNT CALIPER SHOWN. LEFT HAND CALIPER
HAS BLEED SCREW AND CROSSOVER TUBE REVERSED.
INLET FITTING: 1/8-27 NPT
1.62 (41,1)
MOUNT HEIGHT
"D1"
DISC WIDTH
"B"
MOUNT OFFSET
SMALL PISTON LARGE PISTON
5.98 (152,0)
MOUNT CENTER
"E"
OUTSIDE
RADIUS
DISC/WHEEL CENTERLINE
9.44 (239,8)
DISC ROTATION
TOP OF FRICTION MATERIAL
AND DISC O.D. TO BE FLUSH
2.41
(61,2)
2.41
(61,2)
BILLET SUPERLITE 4R/ST CALIPER, MOUNTING DIMENSIONS:
BILLET SUPERLITE 4R/ST ORDERING INFORMATION: USER SERVICEABLE COMPONENTS:
INBOARD OUTBOARD THERMLOCK PAD WEAR CROSSOVER BLEED SCREW BRIDGE BOLT SQ RING
ASSEMBLY BODY BODY PISTON PLATES TUBE KIT (4 PK) KIT (4 PK) KIT KIT (6 PK)
120-6541-FS/RS 110-6523 110-6524 200-5407 (1.38”) 300-5922/23 190-5975 220-6069 230-5976 130-5972
200-5415 (1.12”)
120-6542-FS/RS 110-6525 110-6526 200-5407 (1.38”) 300-5922/23 190-5975 220-6069 230-5976 130-5972
200-5415 (1.12”)
120-6543-FS/RS 110-6527 110-6528 200-5411 (1.25”) 300-5922/23 190-5975 220-6069 230-5977 130-5972
200-5415 (1.12”)
120-6544-FS/RS 110-6529 110-6530 200-5411 (1.25”) 300-5922/23 190-5975 220-6069 230-5977 130-5972
200-5415 (1.12”)
120-6545-FS/RS 110-6531 110-6532 200-5411 (1.25”) 300-5922/23 190-5975 220-6069 230-5978 130-5972
200-5419 (1.00”)
120-6546-FS/RS 110-6533 110-6534
200-5411 (1.25”)
300-5922/23 190-5975 220-6069 230-5978 130-5972
200-5419 (1.00”)
120-6547-FS/RS 110-6535 110-6536
200-5415 (1.12”)
300-5922/23 190-5975 220-6069 230-5978 130-5972
200-5419 (1.00”)
120-6548-FS/RS 110-6537 110-6538
200-5415 (1.12”)
300-5922/23 190-5975 220-6069 230-5978 130-5972
200-5419 (1.00”)
120-6549-L/R 110-6539 110-6540 200-5419 (1.00”) 300-5922/23 190-5975 220-6069 230-5978 130-5972
1.14 (28,9)
NOTE: BRACKET KIT INCLUDED STUDS, LOCKNUTS, WASHERS AND ALIGNMENT SHIMS
3.50 (88,9)
MOUNT CENTER
.26 (6,6)
1.64 (41,7)
.45 (11,4)
MOUNT HOLE
5.98 (152,0)
TYPICAL MOUNTING DIMENSIONS, BSL4R BRACKET KIT, P/N 250-6309:
