Wilwood Promatrix Front Replacement Rotor Kit - Manual (Page 2)

Exploded Assembly Diagram
4
3
2
5
1
RIGHT HAND SIDE SHOWN
EXISTING AXLE
ASSEMBLY
SRP DRILLED/SLOTTED PATTERN
GT SLOT PATTERN
Figure 1. Typical Installation Configuration
WARNING
INSTALLATION OF THIS KIT SHOULD ONLY BE
PERFORMED BY PERSONS EXPERIENCED IN
THE INSTALLATION AND PROPER OPERATION
OF DISC BRAKE SYSTEMS.
NOTE
SPECIFIC PARTS MAY VARY FROM DIAGRAM
Page 2
Important Notice - Read This First
Before any tear-down or disassembly begins, review the following information:
• Due to OEM production differences and other variations from vehicle to vehicle, the fastener hardware and
other components in this kit may not be suitable for a specific application or vehicle.
• It is the responsibility of the purchaser and installer of this kit to verify suitability / fitment of all components
and ensure all fasteners and hardware achieve complete and proper engagement. Improper or inadequate
engagement can lead to component failure.
Photographic Tip
We suggest you take digital photos of the brake system setup before and during the disassembly procedure. This will aid in the event
that something is not compatible with the new brake components and be a valuable tool to assist in the trouble-shooting process.
