21
Series 2 Chain Conveyors
Problem Cause Solution
Low capacity Improper chain speed Check the shaft RPM
Improper feed Check the grain level at inlet
Plugging Check the discharges
Noisy operation Loose UHMW Paddles Check all bolts on chain
Bottom or Sides Not Aligned Check Intermediate Trough Section
joints and make flush
Worn Drive Components Check oil level and shaft seals
belt misalignment; loose belts
Worn Sprocket Replace
Return Rail Alignment Check Rail Alignment
Uneven UHMW Conveyor Misalignment Check the conveyor alignment
paddle wear Sprocket Slipped Check set screws on sprockets
Return Rail Alignment Check Rail Alignment
Excessive carry-over Gates Not Fully Opening Check the gate operation
Uneven sprocket wear Worn chain Replace chain (see pg. 13)
Improper alignment Check the sprocket alignment
Material carry-over Check for improper location
into discharge sprocket of inlet (see pg. 11)
Consult your contractor for added assistance.
Trouble Shooting
Trouble Shooting Guide
