Series 2 Chain Conveyors
The head and tail sections of the chain conveyor are shipped pre-assembled direct from the factory. Intermedi-
ate trough sections come both factory pre-assembled or unassembled. Your order will serve as a reference to
how your trough section should arrive. If you have any questions, please refer to your order confirmation.
Head Assembly
Tail Assembly
Intermediate Trough Assembly
Installation
Typical Intermediate Trough Section Assembly
