6. Layouts
44 PNEG-1828 42' Dura-Lok Plank and Support Manual
42' Split Plank Layout for Manual
Plank # Length Plank A In Inch In Metric Plank # Length Plank B In Inch In Metric
1 8'-5" 101 256.54
2A 3'-5" 41 104.14 2B 9'-5" 113 287.02
3A 11'-0" 132 335.28 3B 5'-0" 60 152.4
4A 6' - 3-1/2" 75-1/2 191.77 4B 12' - 3-1/2" 147-1/2 374.65
5A 13' - 4-1/2" 160-1/2 407.67 5B 7' - 4-1/2" 88-1/2 224.79
6A 8'-4" 100 254 6B 14'-4" 172 436.88
7A 15'-2" 182 462.28 7B 9'-2" 110 279.4
8A 9'-10" 118 299.72 8B 15'-10" 190 482.6
9A 16'-6" 198 502.92 9B 10'-6" 126 320.04
10A 11'-2" 134 340.36 10B 17'-2" 206 523.24
11A 17'-9" 213 541.02 11B 11'-9" 141 358.14
12A 12'-4" 148 375.92 12B 18'-4" 220 558.8
13A 18'-10" 226 574.04 13B 12'-10" 154 391.16
14A 13'-4" 160 406.4 14B 19'-4" 232 589.28
15A 19'-9" 237 601.98 15B 13'-9" 165 419.1
16A 14'-2" 170 431.8 16B 20'-2" 242 614.68
17A 20'-7" 247 627.38 17B 14'-7" 175 444.5
18A 14'-11" 179 454.66 18B 20'-11" 251 637.54
19A 21'-3" 255 647.7 19B 15'-3" 183 464.82
20A 15'-7" 187 474.98 20B 21'-7" 259 657.86
21A 21'-10" 262 665.48 21B 15'-10" 190 482.6
22A 16'-1" 193 490.22 22B 22'-1" 265 673.1
23A 22'-4" 268 680.72 23B 16'-4" 196 497.84
24A 16'-7" 199 505.46 24B 22'-7" 271 688.34
25A 22'-9" 273 693.42 25B 16'-9" 201 510.54
26A 16'-11" 203 515.62 26B 22'-11" 275 698.5
27A 23'-1" 277 703.58 27B 17'-1" 205 520.7
28A 17'-2" 206 523.24 28B 23'-2" 278 706.12
29A 23'-4" 280 711.2 29B 17'-4" 208 528.32
30A 17'-5" 209 530.86 30B 23'-5" 281 713.74
31A 23'-5" 281 713.74 31B 17'-5" 209 530.86
32A 17'-6" 210 533.4 32B 23'-6" 282 716.28
33A 23'-7" 283 718.82 33B 17'-7" 211 535.94
34A 17'-7" 211 535.94 34B 23'-7" 283 718.82
35A 23'-7" 283 718.82 35B 17'-7" 211 535.94
