4. Monorail Installation
18 PNEG-1828 42' Dura-Lok Plank and Support Manual
Monorail “Rail and Leg Spacing”/“Full Floor Leg Quantity” for 42' Bin Diameter
4.00"
Ring
2.66"
Ring
Eave Height (ft.) Rail Spacing
Reference
Page
Leg Spacing Leg Qty
3 4 11 26 See Page 38 25 438
4 6 16 26 See Page 38 23 475
5 8 22 26 See Page 38 20 543
7 10 27 22 See Page 37 20 603
9 12 33 22 See Page 37 19 633
10 14 38 22 See Page 37 18 667
11 16 43 20 See Page 34 18 713
13 18 48 20 See Page 34 17 753
14 20 54 20 See Page 34 17 753
16 22 59 18 See Page 33 17 824
17 24 64 18 See Page 33 17 824
19 26 70 17 See Page 30 16 897
20 28 75 17 See Page 30 16 897
22 30 81 16 See Page 29 16 931
23 32 86 16 See Page 29 15 992
25 34 92 15 See Page 26 15 996
