iNstAllAtioN ProcedUre
p.n. 96309 v.3.0 2
GeNerAl iNstAllAtioN PrActices
for ease of installation of your Banks stinger ™
system, please read this 16- page owner’s
manual before starting any work. become thoroughly
familiar with all components and phases of the
installation before starting any work.
inspect all components supplied for any foreign
material that may have entered during shipping
& handling.
WARNING! NEVER work under any vehicle
supported only by a jack of any kind. dO nOT
use concrete blocks or other masonry items that may
collapse under the vehicle weight
pay particular attention to the routing of wires
and hoses. keep them away from exhaust heat,
moving parts and sharp edges that may cause cuts or
other damage. route or tie away from critical areas
as required. keep all wires a minimum of 6” from hot
exhaust parts, 8” or more is recommended whenever
possible.
right-hand and left-hand designations refer to the
driver’s right or left, as seated in the vehicle (i.e.:
right-hand refers to the passenger side of the vehicle),
unless noted otherwise.
Notification
The Banks Ram-Air Filter comes pre-oiled and no
oiling is necessary for initial installation. Service
the filter as specified in the Cleaning and Oiling
the Banks Ram-Air Filter Maintenance Section of
this manual. 4.
5.
3.
2.
1.
RAM-AIR INSTALLATION
disconnect both batteries.
2.
pull the crankcase vent hose out of the
turbocharger air inlet hose, then loosen the
air intake hose clamp at the turbo compressor.
remove the air cleaner assembly from vehicle to
expose a hole in inner fender panel.
if the vehicle has a plastic elbow inside the
plastic adapter on the inner fender panel
(between the inner and outer fender panels),
remove this elbow by the following procedure.
This elbow may not be present in ’95 and newer
vehicles, however the banks ram-air inlet duct
can be installed as described in the following
step.
first remove the plastic tapered adapter that
connects the air silencer to the inner fender
panel. squeeze the sides of the adapter together
to free it from the panel. use pliers to pull out the
center button on the plastic retainer pin inside the
elbow, then remove the pin.
next, remove the two upper screws holding the
underhood light assembly to the inner fender
panel. also loosen the battery hold-down clamps
and remove one sheet-metal screw in the inner
fender panel near the front of the battery. See
Figure 1 . now remove the plastic elbow from
within the fender by pulling and wiggling it
rearward and toward the engine. This elbow is
part of a silencer about 16” long, and will require
quite a bit of effort to pull it free from the fender.
if it will not move at all, check to make sure all
sheet-metal screws noted were removed. The
forward most screw near the battery attaches
directly to this duct inside the fender and be
removed.
4.
install the new banks ram-air duct into the
inner fender opening to replace the factory
silencer elbow. Once the new duct has been
squeezed into place inside the fender, reinstall
the factory plastic retainer pin or new pin,
provided, through the 3 ⁄
8
” hole in the duct and
inner fender bracket. push in on the center button
of the retainer pin to lock the pin in place.
reinstall the underhood light assembly screws.
reinstall battery. reinstall the plastic tapered
adapter to the inner fender panel by squeezing
the sides together and engaging it into the edge
of the inner fender panel opening.
GAUGE INSTALLATION (PART 1 OF 2)
5.
loosen the compressor discharge hose
clamp at the turbocharger. remove the
connecting strap between the turbocharger and
the air inlet casting.
1.
3.
