Page 21
96464 v.4.0
21
Your Six-Gun Diesel Tuner displays
the “4,3” diagnostic code (refer
to TROUBLESHOOTING in Section
8 on how to read codes) when it
needs to learn your transmission
configurations. This always occurs
when the Six-Gun Diesel Tuner is first
installed on the truck.
Banks Six-Gun Diesel Tuner is
equipped with advanced safety
features to preserve your automatic
transmission. One of them is the
capability to detect the occurrence
of transmission slip, and it will
automatically derate the engine output
power accordingly. Before this safety
feature can take effect, the Six-Gun
Diesel Tuner needs to learn that your
truck is equipped with an automatic
transmission. (Please read the
“Disclaimer of Liability” on page 4.)
1.
Reconnect all battery terminals.
The following driving test shall be
performed in an area where speeds of
this nature are safe and traffic is light.
For vehicle with a manual transmission,
follow Steps 2 through 3. For vehicle
with automatic transmission, follow
Steps 4 through 6.
While driving, listen for any exhaust
leaks or rattles, or intake boost leaks.
After the engine cools, re-tighten
clamps and hoses if leaks are
detected.
2.
To teach the Six-Gun Diesel Tuner
that your truck is equipped with a
manual transmission, drive the truck at
a vehicle speed of over 50 mph for at
least 2 minutes. The “4,3” diagnostic
code will be eliminated.
3.
If a Speed-Loader is being installed,
go to Section 5, “SPEED-LOADER
MODULE INSTALLATION” on page 22
and follow the procedure; otherwise
proceed to Section 6, “cHEcKING
ENGINE PERFORMANcE” on page
23. Repeat Step 2 if necessary to
eliminate code.
4.
To teach the Six-Gun Diesel Tuner
that your truck is equipped with an
automatic transmission, drive your
truck under light load (under 10psig
boost pressure) with overdrive turned
on (4th gear). Obtain a vehicle speed
of over 60 mph until torque converter
is locked (the torque converter is
usually locked at speeds over 60mph).
Maintain this speed steadily with the
torque converter locked for at least 30
seconds.
5.
continue to drive. Slow down and
turn off overdrive and obtain vehicle
speed of over 41 mph and below
46 mph until torque converter is
locked (with overdrive off the torque
converter is usually locked at speeds
over 40 mph but will disengage at
speeds above 50mph). Maintain
the speed steadily with the torque
converter locked for at least 30
seconds.
6.
Once the transmission is learned,
the “4,3” diagnostic code will be
eliminated. If a Speed-Loader is being
installed, go to Section 5, “SPEED-
LOADER MODULE INSTALLATION” on
page 22 and follow the procedure,
otherwise proceed to Section 6,
“cHEcKING ENGINE PERFORMANcE”
on page 23. If the code is not
eliminated, repeat Steps 4 to 5.
-END, SEcTION 4-
SECTION 4
PERFORMING TRANSMISSION LEARNING PROCEDURE
