HDMI® 1 x 4 Splitter over 2 UTP with IR
Part # 280714
• Allows 1 HDMI Source to be Connected to 4
HDMI Displays Devices over Dual Cat5e/Cat6
Cables
• Transmission Range: Extends 1080p
resolutions up to 100 ft over Cat5e Cables;
Extends 1080p resolutions up to 110 ft over
Cat6 Cables
• High Speed Chip Set that Supports 3D and 4K
x 2K
• Full HD1080P/60HZ
• HDCP Compliant
• Super IR, IR transport channel can be forward
or backward, an IR adapter and transmit and
receive pigtails are needed
• Supports Digital Audio Format, DTS-HD/Dolby-
True HD/LPCM7.1/AC3/DTS/DSD
• Unique Circuit Design Allows for Protection
against High Voltage and Peak Currents
• Tested for Compatibility with all leading HD
Video brands
• Tested with Dolby 7.1 Home Theater Systems
• Locking HDMI Compatible
• Shelf or Wall Mounting
• 9V DC, UL Listed Power Supply for 1 x 4
Splitter Unit
• 1 x 4 Splitter Dimensions: 12.5”W x 1.125”H
x 6.25”D
• Receiver Dimensions (4 Total): 1.75”W x
.875”H x 3.25”D
SPECIFICATIONS
HDMI version ............................................................ HDMI v1.4 with 3D
HDCP version ............................................................ HDCP1.2
Support HDMI resolution ............................................ 1080P/1080i/720P/576i/480P/480i
Support video color bit ............................................... deep color 24bit/36bit
Support Audio Format ................................................ LPCM/Dolby-AC3/DTS7.1/DSD
Input Video signal ...................................................... 5.0Volts/P-P
Output cable distance ................................................. 66 ft 24AWG Cable
Input cable distance ................................................... 66 ft 24AWG Cable
Data transfer speed ................................................... 6.75Gbps
Operating Humidity range ........................................... 5 to 90%RH (No Condensation)
Operating Temperature range...................................... -15 to +55 DegreesC; 5 to 131 Degrees F
Power adapter format ................................................ Input AC (50Hz.60Hz) 100-240V
Power Supply ............................................................ DC 9V
NOTE: 100 ft distance with 2 x Cat 5e and 110 ft distance with 2 x Cat 6 UTP cables.
