FEATURES
The Vanco 280557 HDMI Coaxial Extender uses coaxial cable as the transmission media. Benefits of using the
Vanco 280557 HDMI Coaxial Extender are:
1. The length of HDMI cable is normally offered in fixed length increments and cannot be changed after it
is produced. This is because the HDMI connector can only be effectively soldered and terminated using
tooling, fixtures and eye pattern testing equipment normally only available in a factory. However, coaxial
cables are available in most homes and in many business offices, retail stores, schools, hospitals and
hotels. Most low voltage installers are familiar with coaxial cables and connectors and have the stripping,
crimping, and punch down tools needed for connector termination.
2. The maximum transmission distance for 1080p resolution over good quality RG-59 coaxial cable is 50
meters (164 ft) and over good quality RG-6 is 100 meters (328 ft). To achieve these distances, good
quality compression type BNC connectors must be used. Type F to BNC adapters should not be used,
since they can degrade the quality of the HDMI signal.
3. The transmitter and receiver combination has the ability of buffering and amplifying the HDMI signal.
4. The IR control system is built into the transmitter and the receiver can control the sources from the
displays, or control the displays from the sources.
HDMI® over Single Coaxial Cable Extender
Part # 280577
• Allows HDMI Audio/Video Signals to be
Transmitted Using a single Coaxial Cable
• Transmission Range: Extends 1080p Resolution
Up to 328 ft (100 m) over RG-6 Coaxial Cable
(Dual and Quad-Shielded);Extends 1080p
Resolution Up to 164 ft (50 m) over RG-59
Coaxial Cable
• Works with HDMI and HDCP Compliant Devices
• Supports High Definition Resolution 1080p
• Auto-adjustment of feedback, equalization and
amplification
• LED indicators for power and signal status
• Transfers bi-directional IR control signals.
Includes an IR Receiver and IR Emitter.
• Equipped with ESD (Electro-Static Discharge)
protection
• Mounting ears are supplied
• Power Supply: (2) 5V DC
• Dimensions: 5” W x 1” H x 5” D
