FEATURE PROGRAMMING & OPERATION INSTRUCTIONS
SET SYSTEM INTO PROGRAMMING MODE WITH THE MASTER CODE
IMPORTANT NOTE:
1)
2)
3)
MASTER CODE
The Master Code can be a factory set master code or the private
master code that was set by the owner.
Validate the master code with * *
.
2-beep confirms a valid master code. The Mains LED (Amber) is constantly ON after the system is
set in the programming mode.
DIRECT ACCESS TO PROGRAMMING MODE WITH THE “DAP” CODE – 8 0 8 0
Set System Into Programming Mode With DAP Code In Case Of The Master Code Is Forgotten ! !
The owner requires to apply the following procedures precisely to set the system into
programming mode with the DAP code 8 0 8 0.
1)
2)
3)
4)
5)
DAP CODE
The DAP code is fixed on 8 0 8 0 and it is valid only in the Power-up Period after the Egress Button
is pressed.
Validate the DAP code with the
* * .
2-beep confirms the system is in the Programming Mode; and the Mains LED is constantly ON.
See “RECORD A MASTER CODE” at “Location 01” for the details of programming a new master
code.
NOTE:
If the keypad is linking up with the DA-2800 controller in the Split-decoded operation, it is necessary
to put the controller’s “Link-up Jumper” to “ON” position to get the new Master Code for it. As the
Master Code is also the link-up code of the two units. Do Not Forget to put the Link-up jumper back
to OFF position after the programming. Otherwise, the controller will accept other keypads to link up
with it.
0000
8080
**
**
MASTER CODE
VALIDATION
DAP CODE VALIDATION
10
EGRESS BUTTON
PRESS ONCE
DO NOT TURN OFF POWER while the keypad is in Programming Mode. Otherwise, it may cause
data lost/error to the programmed features in the memory.
The keypad beeps after power up. Wait 1 minute until the end of the power up delay, then key in
the Master Code for setting the system into programming mode.
For the owner’s convenience in programming at the first time, the factory has put a Master Code 0
0 0 0 into the keypad (It is NOT a default code). To compromise security, in all cases, the owner
should program a new Personal Master Code to invalidate the factory set Master Code after the
keypad is owned.
Switch OFF all the power for 1 minute to ensure that the system is fully discharged.
Switch ON power again. The system is in Power-up Mode for 1 minute and the buzzer gives
beeps during the whole period. This is the only time limit for setting the system to Direct Access to
Programming (DAP).
Press the Egress Button (EG IN) once first to enable the DAP function.
Key in the DAP Code 8 0 8 0 and validate it with
* *
, the existing Master Code in the memory
is erased and the power up beep stops. The keypad turns itself into programming mode like using
the Master Code and it is ready to accept the new programming data.
If the Egress Button is not pressed and the DAP code is not keyed in within the power up period,
the system will set itself to normal operation mode. To set it back to power-up mode, repeat
procedures 1-4.
