MML16MC
V. 01 – 14/11/2013 10 ©Velleman nv
Insert a graphic
1. In the text editor, insert the cursor at the end of the sentence.
2. Open the graphic editor (Bmp Graphics menu > Edit Graphic).
3. Select the name from the Select Graph column and click Insert.
4. Close the editor.
5. Send the message to the board .
Delete a graphic
1. Open the graphic editor (Bmp Graphics menu > Edit Graphic).
2. Select a name from the Select Graph column and click Delete.
3. Click Yes.
10. Batteries
Warning
• Do not puncture batteries or throw them in fire as they may explode.
• Do not attempt to recharge non-rechargeable batteries (alkaline).
• Dispose of batteries in accordance with local regulations. Keep batteries away from
children.
To replace the battery of the remote control:
1. Slide open the battery cover at the back and replace with a correct batteries (see Technical
Specifications). Respect the polarity.
2. Close the battery cover.
Note: battery in message board.
The message board contains a CR2032 battery used for the device's internal memory. If you unplug the
board and notice that the device does no longer remember the date and time, unscrew the board cover
and insert a new battery of the same type.
11. Technical Specifications
display resolution 7 x 80 dots P6 RGB LEDs
pixel pitch 6 mm
viewing angle 120°
viewing distance 6-25 m
LED configuration 3-in-1 RGB
operating temperature -20 °C to +45 °C
operating humidity 20-90 %
power supply message board: 100-240 Vac 50-60 Hz to 5 Vdc 4 A (adapter incl.);
2.5 x 5.5 mm jack
remote control: 2 x 1.5 V AAA batteries LR6C (incl.)
consumption max. 20 W, average 5 W
dimensions 650 x 17 x 502 mm
viewable area 42 x 480 mm
weight 500 g
spare parts remote control: MMLXXX/RC
Use this device with original accessories only. Velleman nv cannot be held responsible in the
event of damage or injury resulting from (incorrect) use of this device.
For more info concerning this product and the latest version of this manual, please visit our
website www.velleman.eu.
The information in this manual is subject to change without prior notice.
All registered trademarks and trade names are properties of their respective owners and are used only
for the clarification of the compatibility of our products with the products of the different manufacturers.
Windows, Windows XP, Windows 2000, Windows Vista, Windows Aero, Windows 7, Windows 8, Windows
Mobile, Windows Server are registered trademarks of Microsoft Corporation in the United States and
other countries.
